Place of Origin Chongqing, China
Brand Name GOLD
Model Number WDJD-4

WDJD Resistivity Survey Instrument and Deep Ground Water Detector Water Finder







Application:



•  Metal and nonmetal mineral resources detection
•  City geophysical exploration, railway and bridge inspection

•  Hydrology and engineering geology as seeking for ground water, inspecting dam base and flood protection levee for incipient faults

•  Geothermal prospecting





Function:



•  1D resistivity sounding

•  1D induced polarization sounding

•  2D Resistivity imaging





Main Features:


•   Transmitting unit and receiving unit are of all-in-one design, portable and lightweight.


•   Super high-power, high anti-interference performance and precision: up to 6600w (1100v×6A) power, 48Vp-p voltage range ensures to get a good result in a area with high resistance.


•   Automatically achieving compensation of self-potential, drift and electrode polarization, up to ±10V.


•   Receiving unit support transient over-voltage protection, transmitting unit supports over-voltage protection, over-current protection and AB open-circuit protection.


•   For general resistivity and IP survey function, 9 types of electrode arrays are available. Electrode distance (namely “Program”) can be inputted or called. Geometric factor K can also be generated automatically or calculated manually.
     For multi-electrode 2D resistivity imaging, up to 18 electrode arrays are available. It could scanning measure according to fixed section (including AMNB, ABMN, AMBN, AMN, MNB, A-MN-B, Sp M, Sp MN, charge M, charge MN) or continuous rolling scanning measure according to variable section (including A-M, A-MN, AB-M, AB-MN, MN-B, A-MN rectangle).


•   Program: the program can memorize 100 groups of electrode distances, avoiding repetitive input. Or you just input a program Id and step to call the corresponding electrode distances.


•  Earth resistance inspection: ground condition can be inspected at any time.


•   Mass data storage: Up to 1GB capacity (extended) enable store 5,000,000 groups measuring data (including current, voltage, SP, Ro, Ms, metal factor, TH, R, J).


•    All parameter and data are under power-failure protection; and thus data will not be lost even thought the system shuts down accidentally.


•    USB port enables it to transfer data to computer.









Technical specification:





WDJD-4 Res/IP Meter

Receiving



Voltage precision

±24V, ±0.4% ± 1LSB, 24 bit A/D

Input impedance

≥50MΩ

Apparent polarizability precision

±1% ± 1LSB

SP compensation range

±10V

Current channel

6 A, ±0.4% ± 1LSB, 24 bit A/D

Resolution

Voltage: 0.1 micro volt; Current: 0.2 micro ampere.

Suppression

≥80dB for 50Hz industrial frequency (common mode interference or differential mode interference).

Transmitting



Max transmitting power

For general Res/IP sounding, 6600W.

For multi-electrode Res imaging, 1125W, limited by WDZJ-4 switcher

For Res cable, 1350W

For IP cable, 2400W

Max voltage

For general Res/IP sounding, ±1100V (2200V peak to peak)

For multi-electrode Res imaging, 450V DC (limited by WDZJ-4 switcher)

Max current

For general Res/IP sounding, ±6A

For multi-electrode Res imaging, 2.5A DC (limited by WDZJ-4 switcher

Pulse width

1~60s, duty ratio 1:1

Others



Display

160 × 160 dot matrix LCD

Storage

≤1GB

Working temperature

-10°C~+50°C, 95 %RH

Storage temperature

-20°C~+60°C

Instrument power

internal 12V 9Ah rechargeable battery , lasts for 30 hours (or 12V external power supply)

Weight

≤ 4.4 Kg

Dimension (L×W×H)

270mm X 246mm X 175mm





WDZJ-4  Switcher

Max electrode connected

60 and 120 (for option)

Insulation impedance

≥500MΩ

Max working voltage

500VDC

Max working current

2.5ADC

Power supply

Internal 7.4V 4AH rechargeable lithium battery, last for continuously 25 hours work

Working temperature

-10°C~+50°C
