HZ-130YY Water drilling machine for sale
Introduction about Water drilling machine:
High efficiency small portable hydraulic core drilling rig is applicable for highway and building
construction foundation,general survey, geophysical exploration and so on. The portable
hydraulic core drilling rig has wide usage, the portable hydraulic core drilling rig is also suitable
for different rock hardness.
Character about HZ-130YY Water drilling machine:
1.Keeping bracket is installed on the hoist to form a double wheel support structure, able to withstand strong blow.
2.Vertical box are fixed by four groups of bearings to ensure that the rotary machine has sufficient rigidity to overcome gravel layer and other complex geological conditions.
3.The machine is equipped with national patent technology-taper clutch, with characteristics of
strong transmission torque, easy operation and free maintenance.
4.53x59 drilling rod adopted, high rigidity and strong delivery torque.
Detailed data about Water drilling machine:
Unity machine parameter | |
Drilling depth |
130m |
Maximum open hole caliber |
260mm |
End hole caliber |
75mm |
Drill rod caliber |
50mm |
Drilling angle |
90~75 |
Drill weight (No include power) |
510 560kg |
Unity machine dimensions |
2.5×1×1.3 2.5×0.9×1.3m |
Spindle | |
spindle speed |
142,285,570r/min |
Spindle stroke |
450mm |
Hoist | |
Max.single line hoisting capacity |
960kg |
Single line lifting speed |
0.41,0.82,1.64m/s |
Tightrope caliber |
27m |
Mud pump | |
Type |
Horizontal single urn twin-action |
Displacement |
95/77L/min |
Diesle engine |
S1105model 18HP |
Electric motor |
Y160M—4 11kw 1440r/min |
Maximum pressure |
1.2Mpa |
Work pressure |
0.7Mpa |
Water inlet caliber |
30mm |
Water to exit caliber |
25mm |
Triangle conveyer belt |
B1575mm |
Water drilling machine in the factory:
Spare parts:
Welcome to visit us!
Any questions about Water drilling machine,please contact Elsa.
Phone/whatsapp/wechat:0086-15922980256
Skype:goldinstrument
