Home > Products > Hose Clamp > Stainless Steel Quick Release Hose Clamp Pipe Clamps
Stainless Steel Quick Release Hose Clamp Pipe Clamps
- 800000 Piece / Pieces per Month
- shanghai
- Credit Card
-
FK-ETD34 clamp, ETD34 transformer clamp, interlocking style, made of SUS301 stainless steel, with good elasticity, easy assembly of the product, and stable fastening force.
-
Stainless Steel 304 Single Pin Heavy Duty Tri Clamp sanitary clamp with wing nut
-
FK-ETD54 clip clamp,material sus301 stainless steel,Surface Cleaning，Easy to assemble, stable clamping force.
-
RM14 Clamp, RM14 Double PIN clip , RM14 core clamps,wholesale inventories, quality assurance, delivery fast. Can provide customers with matching Core and Bobbin
-
RM12 transformer clamp，RM12 with PIN, RM12 core clamps,wholesale inventories, quality assurance, delivery fast. Can provide customers with matching Core and Bobbin
-
DIN3352 F4 Resilient Non-rising Gate Valve
Product Details
| Place of Origin: | Jiangsu, China | Brand Name: | Tello | Model Number: | 304 |
| Usage: | Pipe Clamp | Material: | Other, Stainless Steel, Stainless Steel | Structure: | T Clamp |
| Standard or Nonstandard: | Standard |
Product Description
Stainless Steel Quick Release Hose Clamp Pipe Clamps
| KHxx | KHxxSS | KHFxxSS | KHLxxSS |
Material for Band | AISI 200 Series SS | AISI 200 Series SS | AISI 300 Series SS | AISI 316 SS |
Material for Housing | AISI 200 Series SS | AISI 200 Series SS | AISI 300 Series SS | AISI 316 SS |
corrosion resistance | ordinary | good | better | Best |
Rated Ultimate Torque | 50in.lbs. min.(5.6Nm) | 60in.lbs. min.(6.8Nm) | 60in.lbs. min.(6.8Nm) | 60in.lbs. min.(6.8Nm) |
Recommended Installation Torque | 30-40in.lbs.(3.4-4.5Nm) | 35-45in.lbs.(4.0-5.1Nm) | 35-45in.lbs.(4.0-5.1Nm) | 35-45in.lbs.(4.0-5.1Nm) |
Clamp Series | "A" Diameter Range | |||||||
SAE Size | KHxx | KHxxSS | KHFxxSS | KHLxxSS | Millimeters | Inches | ||
Min. | Max. | Min. | Max. | |||||
8 | EH8 | EH8SS | EHF8SS | EHL8SS | 11 | 23 | 7/16 | 29/32 |
10 | EH10 | EH10SS | EHF10SS | EHL10SS | 14 | 27 | 9/16 | 1-1/16 |
12 | EH12 | EH12SS | EHF12SS | EHL12SS | 18 | 32 | 11/16 | 1-1/4 |
16 | EH16 | EH16SS | EHF16SS | EHL16SS | 19 | 38 | 3/4 | 1-1/2 |
20 | EH20 | EH20SS | EHF20SS | EHL20SS | 21 | 44 | 13/16 | 1-3/4 |
24 | EH24 | EH24SS | EHF24SS | EHL24SS | 27 | 51 | 1-1/16 | 2 |
28 | EH28 | EH28SS | EHF28SS | EHL28SS | 33 | 57 | 1-5/16 | 2-1/4 |
32 | EH32 | EH32SS | EHF32SS | EHL32SS | 40 | 64 | 1-9/16 | 2-1/2 |
36 | EH36 | EH36SS | EHF36SS | EHL36SS | 46 | 70 | 1-13/16 | 2-3/4 |
40 | EH40 | EH40SS | EHF40SS | EHL40SS | 52 | 76 | 2-1/16 | 3 |
44 | EH44 | EH44SS | EHF44SS | EHL44SS | 59 | 83 | 2-5/16 | 3-1/4 |
48 | EH48 | EH48SS | EHF48SS | EHL48SS | 65 | 89 | 2-9/16 | 3-1/2 |
Stainless Steel Quick Release Hose Clamp Pipe Clamps
Other Type:
1)America style hose clamp(12mm,12.7mm,14mm)
2)stainless steel hose clamp with handle
3)heavy duty stainless steel hose clamp/strong stainless steel hose clamp
4)quick/fast realsed stainless steel hose clamp
5)double wire hose clamp
6)two bolt hose clamp
OEM service available
Completely made of stainless steel. It is the most powerful hose clamp within the product range.
Material:201
304 0Cr18Ni9 304L 00Cr19Ni10
321 0Cr18Ni9Ti 316 0Cr17Ni12Mo2
316L 00Cr17Ni14Mo2 310S 0Cr25Ni20
Samples display:
Other type sample display:
Factory show:
Work processing:
Ready for delivery :
The other type clamps we make include: American type hose clamp,German type hose clamp,Double wire hose clamp,T bolt hose clamp,Rubber band clamp,Heavy duty hose clamp,Hose clamp with handle.etc
