Sodering Iron Electric Ceramic Cartridge Heater

Specifications

This heater is specifically designed for water,oil, chemical,glue,molding,medicine,and other areas.

Specification:

Length:60mm;

OD:3.8mm

Voltage:<220V

Watt: <100W

We provide standard products in different type according to customers' rdifferent equirement.

Ceramic heater is made by printing resistance slurry onto the alumina raw ceramic green sheet, then burn it under 1700 degree, and then get the nickel lead wire welded onto the ceramic body. In this way, the product comes to be a medium low temperature heating element, serving as a new product replacing heating alloy and PTC heating element . It's widely used for medium and low temperature heating in agricultural technology, communication, Medicare and routine life, such as ventilator, heater, heating auxiliary to air-conditioner, industrial drier, air dryer, electric heating splint, electric iron, direct/curving hair iron, vacuum flask, electric cooker, water heater, industrial drier, electric bonder, capper, UTR cylinder condensation-proofer, IR physiotherapy equipment, intravenous injection heating, quick food heating, mini thermostatic bath for special crystal parts. etc

Ceramic heater has many excellent advantages that do not exist in the traditional heating elements.
1. Compact and Light Weight and Energy-saving
High watt density, Good thermal efficiency.
2. Superior Thermal Properties
Fast heating speed.
Customer designed temperature distribution available.
High insulation, allow direct contact with water, kerosene and metal.
3. High Reliability
Superior dielectric strength and electrical insulation.
Long life due to oxidation-proof design on receptivity material.
Superior chemical resistance.
4. No electric noise, white, tidiness, non-rust, non-pollution, non-rupture, no weak soldering.
