Specifications
1. Automatic dispenser for paint tinting2. High precision and repeatbllity
3. Flexible dispenser software
4.CE certificate
Fully Automatic Control Color Mixing Dispenser
Model: HT-10A
This machine can be interfaced to any conmupter via a standard RS-232 connection. Basic machine functions can also be performed without having the computer attached.
The fully automatic dispensing process is assured by advanced computerized controls.
Easy to use, maintain and extremely safe for the operator.
Its smart design and revolutionary software enable it to dispense colorants with remarkable precision in even the smallest quantities, eliminating formula scaling and rounding issues and ensuring color repeatability across machines. It is the best choice of paint shop or distributor.
Technical Data:
|
Compatible with water, oil, unvisal and light solvent colorants RS-232 Port or serial USB adaptor |
| Number and Capacity of Canister | 16 canister x 2.3 |
| Canister Material | OPP plastic or 304 stainless steel |
| Piston Pumps Body Material | Stainless steel |
| Piston Material | Double-decked PTFE |
| Min. Accurate Discharge | 1/384 of fluid ounce or ml |
| Max. Pump Discharge | 60ml or 2 fluid ounces per stroke |
| Nozzle Purging |
Automatic for single or all canisters (purge volume can be adjusted) |
| Colorant Mixing | Automatic (1 minutes to 12 hours waiting, 1 to 20 minutes mixing) or manually controlled |
| Max. Paint Container Size | 320 x 380mm |
| Power Source | 220VAC ±10% 50Hz |
| Max. Power Consumption | 100W (do not contain the computer equipments) |
| Machine Size | 1480(H) x 820(W) x 900(D)mm |
| Shipping Size | 1495(H) x 880(W) x 975(D)mm |
| Machine Weight | 176Kg |
| Shipping Weight | 240Kg |
| Dispenser Computer | No special requirements, can be purchased by the end user |
Main Features:
- The dispenser software is extremely flexible, is compatible with different tinting systems and can be easily interfaced with the majority of formula books and color matching software.
- Usual operations as purging, dispensing, canister filling, colorant mixing etc. are easy and very quick to perform.
- Operator errors are virtually eliminate using real-time dispensing control and an accurate error handling software.
- Access to last dispensed formulas, saved recipes and client files is unlimited. Formula information can be easily printed or stored for future usage.
- Level of colorants in each canister can be visualized and managed at a glance.
- Both the automatic purging function and hermetic nozzle caps assures clean and accurate dispensing all the time.
- Full control on individual pumps and valves speed allows to perform accurate dispensing even with high viscosity colorants.
- The base can lifter is controlled by different sensors to make the can positioning accurate and extremely safe for the operator.
- The can sensor also avoids dispensing when the base can is not properly positioned.
After Sales Service:
The above machine which we supply it to you, we can give you one years after sales warranty, we can also send our engineer to you factory to install this equipment and train your staff, but the Buyer should pay the round air ticket cost and arrange the hotel accommodation as well as the means for Seller’s engineer.
Payment terms:
30% deposit by T/T before production, 70% balance should be paid by T/T before shipment. but we also accept L/C.
Package:
Pack in 1 case: 91x99x159cm
1. Wrap with plastic film
2. Pack in wood or non- wood case
Shipment terms:
We usually take EXW, but we can also accept FOB, CNF, CIF.
Your satisfaction, our destination.
Saving your money by contact us now...
