Hand pushed Samll Concrete Mixer Equipment
BASIC INFORMATION
PRODUCT PARAMETER
| MODEL | 120L | 140L | 160L | 180L | 200L | 220L | 240L |
| MOTOR POWER | 550W | 550w | 550w | 550w | 650w | 650w | 650w |
| VOLTAGE | 220--240V 50HZ / 110-120V 60HZ | ||||||
| CARTON DIMENSION | 79x74x44 | 81×74×44 | 81×74×47 | 81×74×50 | 81×74×53 | 81×74×56 | 81×74×59 |
| UPPER DRUM THICKNESS | 1.5mm | 1.5mm | 1.5mm | 1.5mm | 1.5mm | 1.5mm | 1.5mm |
| LOWER DRUM THICKNESS | 2.0mm | 2.0mm | 2.0mm | 2.0mm | 2.0mm | 2.0mm | 2.0mm |
| DRUM DIAMETER | 71.5CM | 71.5CM | 71.5CM | 71.5CM | 71.5CM | 71.5CM | 71.5CM |
| DRUM MOUTH | 38CM | 38CM | 38CM | 38CM | 38CM | 38CM | 38CM |
| GEAR MATERIAL | CAST IRON | CAST IRON | CAST IRON | CAST IRON | CAST IRON | CAST IRON | CAST IRON |
| N.W/G.W | 49/52 | 51/54 | 53/57 | 55/59 | 57/61 | 59/63 | 61/65 |
| MOTOR SPEED | RPM1380-1400 | RPM1380-1400 | RPM1380-1400 | RPM1380-1400 | RPM1380-1400 | RPM1380-1400 | RPM1380-1400 |
| DRUM SPEED | 28RPM | 28RPM | 28RPM | 28RPM | 28RPM | 28RPM | 28RPM |
| WHEEL SIZE | 9 "x2.17 " | 9 "x2.17 " | 9 "x2.17 " | 9 "x2.17 " | 9 "x2.17 " | 9 "x2.17 " | 9 "x2.17 " |
| INSULATION LEVEL | IP00 | IP00 | IP00 | IP00 | IP00 | IP00 | IP00 |
PRODUCT DETAILS
PRODUCT ADVANTAGE
- Resonable structure and uniform mixing
- Small volume with high capacity.
- Easy installation.
ABOUT AFTER-SALE SERVICE
*Warranty: The company's mixer products is with one year warranty (non-human damage), the wheel bolt and other vulnerable parts are not within the scope of the warranty
*The following circumstances do not implement the warranty, can be charged with maintenance
1,Damage caused by consumers’ improper use, maintenance and custody
2,The damage caused by people beside the company’s personnel
3,Damage caused by force majeure
4,Wearing parts or the product problem is beyond warranty period
BRAND INTRODUCTION SERVICE IDEA - People-oriented, customer oriented, innovation oriented
GRZE is a modern enterprise and professional manufacturer of mixer, with excellent corporate culture, advanced business philosophy, prudent business style, Has been set a good image in the market. The company has advanced technology and equipment, rich manufacturing experience, perfect physical and chemical testing equipment, product qualified rate is up to100%. The Enterprise have passed ISO9001: 2000 international quality system certification, CE certificate and so on.
PRODUCTION EQUIPMENT
CERTIFICATES
HARDWARE SHOW WE ATTENDED
PACKAGE AND SHIPPING
| TYPE | MODEL | CARTON DIMENSION | N.W/G.W | QTY. OF 20'FT | QTY. OF 40'FT | QTY. OF 40'HQ |
|
HORIZONTAL TYPE |
120L | 79x76x43 | 65/69 | 105 | 225 | 225 |
| 140L | 79x76x44 | 66/69 | 105 | 225 | 225 | |
| 160L | 79x76x45 | 67/70 | 84 | 180 | 225 | |
| 180L | 79x76x46 | 68/71 | 84 | 180 | 225 | |
| 200L | 79x76x53 | 71/75 | 84 | 180 | 225 | |
| 220L | 79x76x56 | 73/77 | 84 | 180 | 225 | |
| 240L | 79x76x59 | 75/79 | 63 | 135 | 180 | |
| HAND-PUSHED TYPE | 120L | 79x74x44 | 49/52 | 105 | 216 | 261 |
| 140L | 81×74×44 | 51/54 | 84 | 180 | 210 | |
| 160L | 81×74×47 | 53/57 | 84 | 180 | 210 | |
| 180L | 81×74×50 | 55/59 | 84 | 180 | 210 | |
| 200L | 81×74×53 | 57/61 | 84 | 168 | 189 | |
| 220L | 81×74×56 | 59/63 | 84 | 168 | 189 | |
| 240L | 81×74×59 | 61/65 | 84 | 168 | 189 |
WE CAN FOLLOW CUSTOMER'S PACKING DESIGNS. IF YOU HAVE ANY REQUIREMENT ABOUT THE PACKAGE PLEASE FEEL FREE TO LET US KNOW.
