Split Flat Plate Solar Water Heater

Name: Split Flat Plate Solar Water Heater
Brand: TONG HUA
SKU: 128769783

Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

TONG HUA

Model Number:

Split Flat Plate Solar Water Heater

Haining Tonghua Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name TONG HUA

Model Number Split Flat Plate Solar Water Heater

Specifications

Split Flat Plate Solar Water Heater, CE Solar Keymark Certificate, flat plate solar water heater

Split Flat Plate Solar Water Heater Characteristics:

1) Special design for Europe market .

2) Special Anodized aluminum alloy frame to ensure handsome appearance

3) Can accept high pressure without leakage50mm fiberglass insulation

4) EPDM seal strip to assure the solar collector can work under harsh and very cold temperature

5) Operation Temperature -33120

6) Patterned temper glass or low iron temper glass (4mm thickness)

7) Is not easy broken with very high transmission and low emission

8) Black chrome or Magnetic blue sputtering coating has very higher absorption rate to ensure the high efficiency.

Description	Specification
Collect type	TH-GH-0.8
Dimension	800X1000X80mm
Gross area	0.8
Aperture area	0.65
Absorber area	0.7
Total weight of empty collector	18kg
Transparent cover
Number of covers	1
Cover material	tempered glass
Cover thickness	3.2mm
Cover transmission	92%
absorber
Material	Imported Aluminum Board
Surface treatment	Black chromed/blue sputtered
Construction type	Grid type-horisontal or vertival
Header material	Copper TP2/CA1220
Header tuber size	Φ22mmX0.6
Riser material	Copper TP2/CA1220
Riser tuber size	Φ8mmX0.6
Fill capacity	10 L including the header pipe
Thermal insulation
Insulation material	Fiber glass Insulation
Insulation thickness	Back 45±5mm
Conductivity(w/mk)	0.048w/m.k under test temperature 70°C
Casing
Frame	Aluminum alloy
Frame color	Silver/ Black
Back plate	Iron plate with zinc/ Aluminum plate
Max operation temperature	95°C
Maximum pressure	1400kpa
Sealing gasket	EPDM
Limitations of operation
Max. working temperature	120
Max. working pressure	10bar
Max. pressure that cover can support	1000pa
Max. pressure allowed between fixing and case	1000pa
Recommended circulation flow	Glycol/water
Resistance to freezing	Not under minus 33°
