Work Principle
The load cell’s out–put signal is digital, parameter adjustment and temperature compensation will be finished in internal. Though 470MHz wireless module to launch after reasonable.
Handheld receive load cell output and its internal battery power consumption values then show them on the LCD display ,and handheld through RS232 output to computer or large-screen display.
Product Characteristics
Display: LCD 71×29 with backlighting , 6 bit show weight value
Hold on the peak value, can contact with computer or large-screen display by RS232
Unit: kg,lb,t
Technical Parameter
Wireless Frequency: |
430~485MHz |
Wireless Distance: |
Min:200m(default) |
A/D Conversion Rate: |
≥50times/seconds |
Operating Temp. Range: |
-20~+80°C |
Operating Humidity: |
≤85%RH under 20°C |
Battery Life: |
≥50 hours |
Non-Linearity: |
0.01%F.S |
Stable Time: |
≤5 seconds |
Citation: |
GB/T7551-2008/ OIML R60 |
Notice
Do not use the wireless load cell in explosive and unsafe place. The wireless range will be effective when in different weather, the load cell with the indicator in different place, orientation or obstruct from .For charge: according to Li-ion battery. Do not excess discharge.
