Home > Electrical & Electronics > Sensor > Pressure Sensor > Tension Type Load Cell

Tension Type Load Cell

Name: Tension Type Load Cell
Brand: GOLDSHINE
SKU: 128765523
Availability: InStock

US$ 65 - 820 MOQ: 1 Unit

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

GOLDSHINE

Model Number:

GS218-M2

Contact Supplier Request Quote Chat Now

Ningbo Goldshine Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name GOLDSHINE

Model Number GS218-M2

Usage Pressure Sensor

Theory Resistance Sensor

Output Other, Analog sensor/Digital sensor

Unit: mm(inch)

Cap./Size	Lmax	L1max	M1	M2	D	L2
50~100kg	184	124	M8	M8	φ24	63.5
250~1000kg	228	124	M12	M12	φ35	63.5
2.5~5t	326	206	M20	M24	φ72	101.6
7.5t	420	280	M24	M24	φ72	139.7

Product Characteristics:
GS218-M2 Load cell are available in the capacities 50kg~10t;50lb~20klb. They offer alloy steel or total stainless steel construction, complete hermetic sealing, oil proof, water proof and anti-corrosion making them suitable for use in all kinds of environments. S beam design, tension and or compression loading possible, easy installation and flexible application. It is suitable for hanging scales, mechanical scales, hopper scales and other electronic weighing devices. It is safety and anti-explosion product that can be used in atrocious weather and hazardous areas.

Technical Parameter:

Rated Load:	0.05/0.1/0.25/0.5/1/2.5/5/7.5/10t 50/75/100/150/200/300/ 500/750/1k/1.5k/2k/2.5k/3k/5k/10k/15k/20klb
Sensitivity:	(2.0±0.1%) mV/V
Combined Error:	±0.02% F.S
Creep Error30min:	±0.02% F.S
Zero Balance:	±1% F.S
Temp. Effect On Zero:	±0.02% F.S/10
Temp. Effect On Span:	±0.02% F.S/10
Input Resistance:	385±5Ω
Output Resistance:	352±2Ω
Insulation Resistance:	≥5000MΩ
Operating Temperature Range:	-30~+70
Maximum Safe Over Load:	150%F.S
Ultimate Over Load:	300%F.S
Recommend Excitation Voltage:	10~12V DC
Maximum Excitation Voltage:	15V DC
Sealing Class:	IP67/IP68
Element Material:	Alloy Steel, Stainless Steel
Cable:	Length=L:2m
Citation:	GB/T7551-2008/ OIMLR60
Mode Of Connection:	Red(Input+),Black(Input-),Green(Output+),White(Output-)
