Home > Electrical & Electronics > Sensor > Pressure Sensor > S Type Tension Load Cell

S Type Tension Load Cell

Name: S Type Tension Load Cell
Brand: GOLDSHINE
SKU: 128765425
Availability: InStock

US$ 48 - 78 MOQ: 5 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

GOLDSHINE

Model Number:

GS202S

Contact Supplier Request Quote Chat Now

Ningbo Goldshine Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo or Shanghai China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name GOLDSHINE

Model Number GS202S

Usage Pressure Sensor

Theory Resistance Sensor

Output Other, Analog sensor/Digital sensor

Dimensions: Unit: mm(inch):

Product Characteristics:
GS202 Load cell are available in the capacities 25kgf~20000kgf. It is used for tension measurements, tensile testing, weighing, industrial alutomoation and research applications. It is universal load cell suitable for both-tension and compression modes. They offer alloy steel or total stainless steel construction, complete hermetic sealing, oil proof, water proof and anti-corrosion making them suitable for use in all kinds of environments. S beam design, tension and or compression loading possible, easy installation and flexible application. It is suitable for hanging scales, mechanical scales, hopper scales and other electronic weighing devices. It is safety and anti-explosion product that can be used in atrocious weather and hazardous areas.

Technical Parameter:

Rated Load:	10/15/20t
Sensitivity:	(2.0±0.1%) m V/V
Combined Error:	±0.02% F.S
Creep Error(30min):	±0.02% F.S
Zero Balance:	±1% F.S
Temp. Effect On Zero:	±0.02% F.S/10
Temp. Effect On Span:	±0.02% F.S/10
Input Resistance:	385±5Ω
Output Resistance:	352±2Ω
Insulation Resistance:	≥5000MΩ
Operating Temp. Range:	-30~+70
Maximum Safe Over Load:	150%F.S
Ultimate Over Load:	200%F.S
Recommend Excitation:	10~12V DC
Maximum Excitation:	15V DC
Sealing Class:	IP67/IP68
Element Material:	A:Alloy Steel, SS:Stainless Steel
Cable:	Length=L:3m(0.025t~3t) ; 5m(5~30t)
Citation:	GB/T7551-2008/ OIML R60
Mode Of Connection:	Red(Input+),Black(Input-),Green(Output+),White(Output-)
