Load Cell Supplier

Ningbo Goldshine Electronic Co., Ltd.
Load Cell Supplier thumbnail-1
Load Cell Supplier photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GOLDSHINE
Model Number:
GS342
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name GOLDSHINE
Model Number GS342
Usage Pressure Sensor
Theory Resistance Sensor
Output Other, Analog sensor/Digital sensor

load cell supplier

Cap.(t)

L

L1

L2

L3

L4

H

H1

d

W

h

S Φ

0.5~2.5

203
(7.99)

102
(4.02)

19
(0.75)

63.5
5(2.5)

98
(3.86)

43
(1.69)

37
(1.46)

13
(0.51)

37
(1.46)

15.4
(0.61)

28
(1.1)

3/4t

203
(7.99)

102
(4.02)

19
(0.75)

63.5
(2.5)

98
(3.86)

52
(2.05)

44
(1.73)

17
(0.67)

40
(1.57)

15.4
(0.61)



5

235
(9.25)

118
(4.65)

21
(0.83)

66.5
(2.62)

124
(4.88)

52
(2.05)

48
(1.89)

21
(0.83)

48
(1.89)

18.16
(0.71)

32
(1.26)

8

235
(9.25)

118
(4.65

22
(0.87)

74
(2.91)

114
(4.49)

52
(2.05)

48
(1.89)

27.5
(1.08)

48
(1.89)

18.16
(0.71)



10

279
(10.98)

140
(5.51)

25
(0.98)

83
(3.27)

140
(5.51)

82.6
(3.25)

60
(2.36)

21
(0.83)

60
(2.36)

28.4
(1.12)

52.8
(2.08)



Product Characteristics:

GS342 load cells are available for manifold accurate measurement in the capacities 0.5t to 10t.

Alloy steel, potted by adhesive inside, steel ball support, oil-proof, waterproof and anti-corrosion, suitable for multiform environment.

Single shear beam and easy for installation, it is suitable for electronic truck scales, track scales, automobile test line ,hopper scales and other electronic weighing devices.

It is safety and anti-explosion product that can be used in atrocious weather and hazardous areas.
Important Features:1.Capacities:0.5t to 10t.     2.High accuracy.

3.Alloy steel construction.   4.Low profile and nice exterior.

Technical Parameter:

Rated Load:

0.5/1/2.5/3/4/5/8/10t

Sensitivity:

(2.0±0.1%) m V/V

Combined Error:

±0.02% F.S

Creep Error(30min):

±0.02% F.S

Zero Balance:

±1% F.S

Temp. Effect On Zero:

±0.02% F.S/10°C

Temp. Effect On Span:

±0.02% F.S/10°C

Input Resistance:

385±5Ω

Output Resistance:

351±2Ω

Insulation Resistance:

≥5000MΩ

Operating Temperature Range:

-30~+70°C

Maximum Safe Over Load:

150%F.S

Ultimate Over Load:

250%F.S

Recommend Excitation Voltage:

10~12V DC

Maximum Excitation Voltage:

15V DC

Sealing Class:

IP67/IP68

Element Material:

Alloy Steel/ Stainless Steel

Cable:

Length=L:6m

Citation:

GB/T7551-2008/ OIML R60

Mode Of Connection:

Red(Input+),Black(Input-),Green(Output+),White(Output-)
