Digital load cell
- 10000 Piece / Pieces per Month
- Ningbo or Shanghai
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | GOLDSHINE | Model Number: | SQB Single Point Load Cell |
Usage: | Pressure Sensor | Theory: | Resistance Sensor | Output: | Other, Analog Sensor / Digital Sensor |
Product Description
digital load cell,column load cell, load cell, pressure sensor, weighing load cell, digital weighing sensor,weight cell;
Product characteristics:
SQB with foot series is single shear beam. One end of the load cell is fixed, another loaded and rocker pressure head transfers force. Easy installation and it is suitable for floor scale, automobile test facilities, hopper scale and other electronic weighing devices
Technical parameter:
Rated load | 0.1t,0.2t,0.3t,0.5t,1t,2t,3t,5t |
Sensitivity | (2.0±0.1%) mV/V ,(3.0±0.1%) mV/V |
Combined error | ±0.02% F.S |
Creep Error30min | ±0.02% F.S |
Zero balance | ±1% F.S |
TCO: | ±0.02% F.S/10oC |
TC Span: | ±0.02% F.S/10oC |
Input resistance: | 385±5Ω |
Output resistance: | 352±2Ω |
Insulation resistance: | ≥5000MΩ |
Operating Temp. Range | -30~+70oC |
Maximum safe over load: | 150%F.S |
Ultimate over load: | 250%F.S |
Recommend excitation: | 10~12V DC |
Maximum excitation: | 15V DC |
Sealing Class: | IP67/IP68 |
Element material: | A: Alloy Steel, SS: Stainless Steel |
Cable: | Length=L:6m |
Citation | GB/T7551-1997/ OIML R60 |
Mode of Connection | Red(Input+),Black(Input-),Green(Output+),White(Output-) |
about us:
Ningbo GOLDSHINE electronic Co., Ltd. located in Ningbo, China is an joint venture enterprise integrating scientific research, production and sales of load cell / sensors, fittings for electric weighing apparatus and automation control systems in various kinds. It specializes in manufacturing high precision load cells and electrical weighing systems. Strictly according to the OIML R60 and ISO9001:2000, we can supply various load cells with high precision, reliable capability and super advantages in anti-erosion,waterproof, anti-explosion, shockproof and anti-lightning as well. Company carries out modern enterprise management system, And the brand "GOLDSHINE" we developed by ourselves enjoys high reputation in weighing apparatus industry. Now we have a widely,market in international market. At present we can produce various types load cell from 50g-500t for many industrial, at the same time we can produce according to customer’s requirement supply technical service, and make sure the continuous quality improvement by reform and development.
