Profile:
Wireless dynamometer / wireless dyna-link SW6W wireless Dyna-link load guage is an extremely well-built instrument for industry use ,as a standard wireless tool offer universal applications, Whether used as conventional crane weigher or to measure force, ERT wireless Dyna-link load guage is microprocessor controlled for precision accuracy, calibration is easier with wireless indicator.
Standard Features:
Rugged construction. Accuracy: 0.05% of capacity. All functions and units are clearly display on the LCD (with backlighting).Digits are 1 inch high for easy distant viewing. Two user programmable Set-Point can be used for safety and warning applications or for limit weighing. Long battery life on 3 standard “LR6(AA)”size alkaline batteries. All commonly used internationally recognized units are available:kilograms(kg), short Tons(t) pounds(lb),
Technical Data:
Display: |
25mm (1’’) 5digits LCD |
Power On Zero Range: |
20% F.S. |
Manual Zero Range: |
4% F.S. |
Tare Range: |
20% F.S. |
Stable Time: |
≤10seconds; |
Overload Indication: |
100% F.S. + 9e |
Max. Safety Load: |
125% F.S. |
Ultimate Load: |
400% F.S. |
Battery Life: |
≥40 hours |
Battery Type: |
“LR6(AA)”size alkaline batteries. 1.5V*3 |
Operating Temp: |
- 10°C ~ + 40°C |
Operating Humidity: |
≤85% RH under 20°C |
Remote Controller Distance: |
Min. 15m |
Wireless Frequency: |
2.4GHz(default),433MHz,860MHz(optional) |
Wireless Distance: |
Min. 80m(default) [200m(optional)] |
Work Principle:
The load cell’s out–put signal is digital, parameter adjustment and temperature compensation will be finished in internal. Though 470MHz wireless module to launch after reasonable.
Handheld receive load cell output and its internal battery power consumption values then show them on the LCD display ,and handheld through RS232 output to computer or large-screen display.
