Features:
Crane scale JXCS-E Multi-weighing units: Kg, lb, N are selectable, generally kg is the default unit. Multi-function operation: Tare;Zero;Auto zero tracking;Total;Hold; Overload warning, Oration through remote controller functions. User-friendly design: Cast aluminum housing and aluminum front panel for maximum protection; Large red 5 digit LED display (digit height: 30mm); Battery Operated with low battery indication; Automatic switch-off power-saving function.
Main Technical Data:
Standard: |
According to OIML class III |
Display: |
30mm (1.2'') 5digits LCD/LED |
Zero Range: |
4% F.S. |
Tare Range: |
20% F.S. |
Stable Time: |
≤10 seconds |
Overload Indication: |
100% F.S. + 9e |
Max. Safety Load: |
125% F.S. |
Ultimate Load: |
400% F.S. |
Battery Life: |
≥70 hours |
Battery Type: |
Fully sealed Lead-Acid battery, 6V/7Ah |
Adapter: |
DC9V/1000mA |
Operating Temp.: |
- 10°C ~ + 40°C |
Operating Humidity: |
≤85% RH under 20°C |
Remote Controller Distance: |
Min. 15m |
Wireless communicator: |
(Opertion) 485MhZ Connect the Indicator :JX280 or JX680 |
Specification:
Model |
Max Cap.(Kg) |
Min. Weigh (Kg) |
Division (Kg) |
Total Display Counts (N) |
JXCS -1-E |
1000 |
10 |
0.5 |
2000 |
JXCS -2-E |
2000 |
20 |
1 |
2000 |
JXCS -3-E |
3000 |
20 |
1 |
3000 |
JXCS -5-E |
5000 |
40 |
2 |
2500 |
JXCS -10-E |
10000 |
100 |
5 |
2000 |
JXCS -15-E |
15000 |
100 |
5 |
3000 |
JXCS -20-E |
20000 |
200 |
10 |
2000 |
MODEL |
A(mm) |
B(mm) |
C(mm) |
H(mm) |
N.W |
JXCS -1-E |
90 |
280 |
40 |
580 |
16kg |
JXCS -2-E |
90 |
280 |
40 |
580 |
16kg |
JXCS -3-E |
90 |
280 |
40 |
580 |
16kg |
JXCS -5-E |
110 |
280 |
45 |
670 |
18kg |
JXCS-10-E |
130 |
280 |
60 |
700 |
20kg |
JXCS-15-E |
95 |
280 |
66 |
733 |
50kg |
JXCS-20-E |
125 |
280 |
86 |
800 |
88kg |
JXCS-30-E |
145 |
280 |
101 |
920 |
132kg |
