Home > Products > Crane System > With high precision Crane scale /Easy Install Wired Crane scale
With high precision Crane scale /Easy Install Wired Crane scale
- 5000 Piece / Pieces per Month
- Ningbo or Shanghai
- Credit Card
Product Details
| Place of Origin: | Zhejiang, China | Brand Name: | GOLDSHINE | Model Number: | GS222 |
| Type: | Crane Scale | Power Supply: | 110V/220V | Display Type: | LED or LCD |
| Rated Load: | 150kg | Accuracy: | 10g |
Product Description
Product Characteristics:
GS222 series is special load cell for crane scale. Element material made of alloy steel or stainless steel according to customers requirement. High precision, strong overload protection capacity and anti-deflective loading. We can produce the load cell with analog load cells, digital load cells, wireless load cells, stainless steel load cells, alloy steel load cell, low profile scale beam load cells, high temperature load cell, anti-lighting load cell. The application for the rebuild of crane sinker wheel machine at the port and some simple equipment inspection. Tension weigh modules are designed for use with suspended tanks, dosing hoppers and other devices that are suspended from a support structure. We offer a wide range of capacities to meet the needs of a variety of weighing applications.
Technical Parameter:
Rated load: | 5t/7.5t/10t/12.5t |
Sensitivity: | (2.0±0.1%) mV/V |
Combined error: | ±0.02% F.S |
Creep Error30min: | ±0.02% F.S |
Zero balance: | ±1% F.S |
Temp. effect on zero: | ±0.02% F.S/10 |
Temp. effect on Span: | ±0.02% F.S/10 |
Input resistance: | 385±5Ω |
Output resistance: | 351±2Ω |
Insulation resistance: | ≥5000MΩ |
Operating Temp. Range | -30~+70 |
Maximum safe over load: | 150%F.S |
Ultimate over load: | 200%F.S |
Recommend excitation: | 10~12V DC |
Maximum excitation: | 15V DC |
Sealing Class: | IP67/IP68 |
Element material: | Alloy Steel, Stainless Steel |
Cable: | Length=L:1m |
Citation: | GB/T7551-2008/ OIML R60 |
Mode of Connection: | Red(Input+),Black(Input-),Green(Output+),White(Output-) |
Accessories(Inidcators)
Packing:
