Help CenterSpecial Shape Card Punch Machine
US$ 14,500 - 14,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
GNT
Model Number:
GN-LGDQ-3TAG
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Jiangsu, China
Brand Name
GNT
Model Number
GN-LGDQ-3TAG
Power
Other, Electronic, 4kW
Usage
Other, Cutting plastic cards
Product Description
Product name: Special shape card punch machine
Special shape card punch machine is applied for punching holes, cutting edge and impressing marks on 3-Tag or other irregular shape cards. It is controlled by PLC and operated with touch screen. The hydraulic punch heads are used to punch and impress with low noise level.
Technical parameters:
| Material size | 54*85.6 |
| Max. pressure | 0-1500kg adjustable |
| Punch head number | 2 |
| Power supply | AC380V 50Hz 3-phase 5 line |
| Power | 4KW |
| Air supply | 0.6MPa |
| Air consumption | 12 L/min |
| Productivity | 3500 cards/H |
| Dimension | 700*1100*1600mm |
| Weight | About 600kgs |
