Ultrahigh Molecular Weight Polyethylene Sheet HD200

Name: Ultrahigh Molecular Weight Polyethylene Sheet HD200
Brand: Hongbao
SKU: 128740933
Availability: InStock

US$ 3 - 9 MOQ: 1 Kilogram

Key Specifications

Place of Origin:

Shandong, China

Type:

Synthetic Resin and Plastics

Brand Name:

Hongbao

Ningjin County Hongbao Chem Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao.Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Type Synthetic Resin and Plastics

Brand Name Hongbao

Specifications

1. Non-Toxic and smell
2. Low coefficient of friction
3. Corrosion resistant
4. Abrasion and impact resista

1. Wear resistance is 6-7 times of ordinary carbon steel;

2 impact strength was 4 to 5 times of the ABS;

3.Self-lubricating properties superior;

4. Strong corrosion resistance, high chemical technical;

5 non-stick phase is not easy to attach the product surface and other materials;

6 the impact energy absorption is strong;

7 health non-toxic, low temperature resistance, also have ductility in liquid nitrogen

Inspection Report

Name			UHMW-PE
Inspeciton Content
S/No.		Item		Unit	Test Standard	Result
1		Dentisty		g/cm³	GB/T1033-1966	0.95-1
2		Molding shrinkage%			ASTMD6474	1.0-1.5
3		Elongation at break		%	GB/T1040-1992	238
4		Tensile strenth		Mpa	GB/T1040-1992	45.3
5		Ball Indentation hardness test 30g		Mpa	DINISO 2039-1	38
6		Rockwell hardness		R	ISO868	57
7		Simply supported beam hardness		KJ/m	ISO179	85
8		Bending strength		Mpa	GB/T9341-2000	23
9		Compression Strength		Mpa	GB/T1041-1992	24
10		Static softening temp.			ENISO 3146	132
11		Specific heat		KJ/(Kg.K)		2.05
12		Impact strenth		Kj/m³	D-256	100-160
13		Heat conductivity {w/(m.k)}		%(m/m)	ISO11358	0.16-0.14
14	Sliding properties and friction coefficient				PLastic/stceL(wct)	0.19
15	Sliding properties and friction coefficient				PLastic/stccL(dry)	0.14
16	Antistatic Coefficient				SL-CM	10
17	Water absorption				ASTMD570	<0.01%
