Help Center18W, Dia225*18mm Round LED Downlight Panel,moving Detectable LED Panel Radarers Led Ceiling Panel
Related Products
-
Good Price 5w 12w 18w ul Led Glass Panel Light Square Dimmable Ip44 5600k Led Flat PanelUS$ 5 - 10MOQ: 1000 Pieces -
High Lumen Smd Ultra-thin Round or Square Ceiling Panel Light 3W 4W 6W 9W 12W 15WUS$ 1.2 - 5MOQ: 1000 Pieces
-
Factory UL Quality Glass Cover Led Panel Light 6w 9w 12w 18w Ceiling Lamp LightingUS$ 5 - 10MOQ: 1000 Pieces
-
Factory Direct Supply Price Hot Selling Led Commercial Lighting 6w/12w/18w/24w GlassUS$ 0.9 - 5MOQ: 1000 Pieces
-
18W Dia225*18mm Round LED Downlight Panel Moving Detectable LED Panel RadarUS$ 1.2 - 5MOQ: 1000 Pieces
1. Radar Sensor LED PANEL LIGHT Product Parameter :
Model No. |
JT-BS-r18W | |
| Housing Material | Aluminum | |
| Demension | 225X12mm | |
| Input voltage | 220-240V AC 50-60HZ | |
| Wattage | 18W | |
| Light efficiency | 80Lm/W | |
| Power Factor | >0.6 | |
| LED | Chip | Epistar |
| Type | 2835SMD | |
| Quantity | 90pcs | |
| Luminous Flux | 1300Lm | |
| Color Temperature | 3000K/4500K/6500K | |
| Beam Angle | 120 | |
| Average life | 30000hours | |
| Certificate | CE&RoHS | |
| Warranty | 2 years | |
2. Radar Sensor LED PANEL LIGHT lighing Feature
Power |
Product Size(mm) |
Hole cutting Size(C) |
LED Qty/Type |
Luminous Flux |
I luminance at 1m(±5%) |
Working Voltage current(DC) |
||
size |
cut-out |
|
||||||
6W |
120 |
Ø76 |
|
Ø105mm |
30Pcs/2835 |
380Im |
120.3Ix |
12-25V/300mA |
9W |
145 |
Ø100 |
|
Ø130mm |
45Pcs/2835 |
550Im |
171.4Ix |
25-42V/300mA |
12W |
170 |
Ø124 |
|
Ø155mm |
60Pcs/2835 |
950Im |
303.4Ix |
25-42V/300mA |
15W |
190 |
Ø148 |
|
Ø175mm |
75Pcs/2835 |
1100Im |
357.3Ix |
36-72V/300mA |
18W |
225 |
Ø174 |
|
Ø210mm |
90Pcs/2835 |
1300Im |
423.7Ix |
36-72V/300mA |
Product features:
1. Super bright SMD2835 LED as lighting sources; high efficiency, energy Saving, Eco-friendly;
2. Aluminum alloy frame with high-thermal conductivity, simple and nice;
3. Integrated heat dispersion structure, low lumens depreciation and long lifespan;
4. External constant current driver, universal available;
5. Easy to install.
3. led panel lighting CE/ROHS and CE-LVD Certificate showing:
|
|
|
4. square led panel lighing Production details show :
5. ultrathin 6W led panel light product details:
6. led panel lighing Installation Operation Flowchart: :
7. Trade Terms:
1. Payment terms: 30% deposit , balance before delivery or irrevocable L/C at sight |
| 2. Delivery time: 7-15days after receiving deposite |
3. samples for quality reference are available |
4. Shipping port: Shanghai or Lianyungang |
5. Discounts are negotiable according to ordered quantity |
6. Payment : western unlon ,paypal, Bank of China ( Corporate Account ) |
8. Advantages:
1. We have the R&D department to support and can supply the products according to your design and requirements |
2. Energy saving ,saving 85% than the traditional lights at the same brightness. |
3. Inner high efficiency(95%) heat protection system, with the latest high efficiency and constant currency driver, making the products can work under unstable voltage |
4. Professional circuit design, each LED can work separately, thus it can avoid the influence caused by a broken single LED. |
5. Anti-electric wave,no RF interference |
9. Our service:
1. Your inquiry related to our products or prices will be replied in 24 hours |
2. Well-trained and experienced staffs to answer all your enquires in fluent English |
| 3. OEM&ODM, any your customized lightings we can help you to design and put into product |
4. Distributorship are offered for your unique design and some our current models |
5. Protection of your sales area,ideas of design and all your private information |
| 6. All the products must through 24 hours aging before delivery to ensure the quality again. |
10. Remarks:
1. Non-waterproof,indoor use only.Power off before installing in case of electric shock |
2. Avoid direct strong sunlight and high temperature |
3. When the light is on,do not touch the shell directly in case of being scalded |
4. Any question during installation and using,please consult a professional electrician |
11. About "JUST"
Just light and thanks so much for visting our website As a foreign market oriented led lighting supplier, we sincerely want to say thanks to our customers for their support of our LED products. Though we deeply know that we still have a long way to go in the future , also our products and serive still need to improve, accompanyed by customer, we believe we will do better and better
