Multi-function Gasoline/CNG Mini Truck

Multi-function Gasoline/CNG Mini Truck thumbnail-1
Multi-function Gasoline/CNG Mini Truck photo-1
US$ 2,000 - 2,800 MOQ: 2 Sets
Key Specifications
Get Latest Price
Use For:
Cargo
Driving Type:
Motorized
Displacement:
201 - 250cc
Contact Supplier Request Quote Chat Now
Chongqing Zhuoguan Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Use For Cargo
Driving Type Motorized
Displacement 201 - 250cc
Body Type Closed
Certification Other
Brand Name Zhuoguan
Place of Origin Chongqing, China
Model Number ZG250ZH- Mini Truck
Size 3520*1400*1720MM

Specifications

right hand drive 250cc motorized mini truck/CNG four wheeler/Multi-function gasoline/CNG mini truck
four wheel motorcycle



Multi-function cargo four wheeler



Features:

 *it has afterbunner file

 *it has extra conveyer driven shaft,can drive other machine,such as water pump machine and rice machine etc.



 Specification:





ENGINE AND TANSMISSION



Engine

250CC single cylinder, water -cooled, 4 stroke

Engine Brand

LIFAN

Total displacement

229.2 ml

Bore x Stroke

67X65MM

Compression ratio

9.5:1

Max Power

≥11.8KW/7000 r/min

Max Torque

≥18N·m/5500 r/min

Idling speed

1500 r/min

Ignition

C.D.I

Lubrication

Pressure splash

Transmission

5 speed with reverse

Starter

Kick start&electric start

Final drive

Shaft drive

Oil consumption

≤4.2L in 100KM

PARTS AND COMPONENTS



Chassis

Frame style

Front suspension

Round spring + damper

Rear suspension

New style round + damper

Rear axle

semi-floating type

Brake system

Drum brake/ drum brake

Tyre

4.50-12,4.50-12

DIMENSIONS AND CAPACITY



N.W

500KG

Max loading

800kg-1000kg

Dimension

3520*1400*1720MM

Max speed

70km/h

Ground clearance

165mm

Axle base

1660mm

Wheel base

2150mm

FUEL TANK

20L&30L with CNG

Cargo box

2000*1300mm

Cabin material

Iron

Passenger

2 persons(including driver)

Grade ability

≥28%

Minimum turning diameter

≤8.5M

Angle of approach

23°

Angle of departure

30°

CONTROLS



Control

Steering wheel in right

CLUTCH

Manual, wet, multiple

Loading Capacity:40’HQ container in CKD

6

               20’GP container in CKD

2







































































































Package:



Multi-function gasoline/CNG mini truck







right hand drive 250cc motorized mini truck/CNG four wheeler/Multi-function gasoline/CNG mini truck
four wheel motorcycle
