Cooling Box Tricycle/refrigerator Tricycle Closed Cargo Box

Cooling Box Tricycle/refrigerator Tricycle Closed Cargo Box thumbnail-1
Cooling Box Tricycle/refrigerator Tricycle Closed Cargo Box photo-1
US$ 3,000 - 4,000 MOQ: 10 Units
Key Specifications
Get Latest Price
Use For:
Cargo
Driving Type:
Motorized
Displacement:
201 - 250cc
Contact Supplier Request Quote Chat Now
Chongqing Zhuoguan Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Use For Cargo
Driving Type Motorized
Displacement 201 - 250cc
Body Type Closed
Certification Other
Brand Name Zhuoguan
Place of Origin Chongqing, China
Model Number ZG250ZH refrigerator tricycle
Size 3400*1500*1950mm

Specifications

refrigerated three wheel motorcycle/refrigerated cargo three wheeler
Refrigerator cargo tricycle/frozen box 3 wheeler tricycle

cooling box tricycle/Refrigerator tricycle Specification



Transport food ,keep fresh ,such as ICE CREAM,FISH,MEAT,FRUIT,VEGETABLES



ENGINE AND TANSMISSION



Engine

200CC single cylinder, water-cooled, 4- stroke, manual clutch.

Engine Brand

LIFAN

Total displacement

197.0ml

Bore x Stroke

63.5X62.2MM

Compression ratio

10.16:1

Max Power

≥11.5KW/8000 r/min

Max Torque

≥15.0N.m/6000 r/min

Idling speed

1500 r/min

Ignition

C.D.I

Lubrication

Pressure splash

Transmission

5 speed with reverse

Starter

Kick start&electric start

Final drive

Shaft drive

Oil consumption

≤2.8L in 100KM

PARTS AND COMPONENTS



Chassis

Frame style

Front suspension

Round spring + damper

Rear suspension

New style round + damper

Rear axle

semi-floating type

Brake system

Drum brake

Tyre

4.50-12,4.50-12 (interchange)

DIMENSIONS AND CAPACITY



N.W

350KG

Max loading

600kg

Dimension

3400*1500*1950MM

Max speed

60km/h

Ground clearance

200mm

Axle base

1950mm

Wheel base

2050mm

FUEL TANK

12L

Cargo box

1800*1250mm

Cabin Material

Iron cabin

CONTROLS



Control

Handle Bar

CLUTCH

Manual, wet, multiple

PACKING



Loading Capacity:40’HQ container in CKD

30units

               20’GP container in CKD

10units



refrigerated three wheel motorcycle/refrigerated cargo three wheeler
Refrigerator cargo tricycle/frozen box 3 wheeler tricycle



  cooling box tricycle/refrigerator tricycle closed cargo box





Package:



cooling box tricycle/refrigerator tricycle closed cargo box
