Top in TKA Series Counterbalanced 1500kg 3 Wheels Full Electric Fork Lift

Name: Top in TKA Series Counterbalanced 1500kg 3 Wheels Full Electric Fork Lift
Brand: Noelift
Availability: InStock

FOB Price

US$ 10,000 - 100,000 / Unit

1 Unit(Min. Order)

Port SHANGHAI/NANJING
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Zhejiang, China
Brand Name	Noelift	Model Number	TKA15
Type	Powered Pallet Truck	Power Souce	AC Motor
Rated Loading Capacity	1500kgs	Max. Lifting Height	4500mm
Min. Lifting Height	3000mm	Fork Length	920mm
Fork Width	100mm	Overall Dimensions	1450mm1100mm2070mm
Certification	CE,GOST, ISO9001	After-sales Service Provided	Overseas third-party support available

Product Description

Specifications

1.5ton 3 wheels electric forklift
1Smalle size Suit for working in narrow aisles
2AC driving motor, DC lifting motor cheaper

Product Description

China famous electric forklift brand Noelift TKA15 1.5T 3 wheels full electric forklift hot sales in alibaba made in china CE

1.5TON 3-Wheel Electric Forklift Truck
Rated load capacity: 1000 kg, maximum lift height: 4500mm
AC drive motor with strong applicability suitable for small space operation and storey operation;
1. Safety neutral device which does not allow starting when in a neutral position to enhance security of the car;
2. Curve Safe control to automatically slow down when turning;
3. Safety oil shut-off valve to ensure security of the personnel and cargo;
4. Forward cylinder security locks and variable wheelbase to ensure more security in forklift running;
5. High-strength overhead guard to ensure safety of the operating personnel;

Product Parameter

TKA- 3-wheel electric forklift truck 24V

1	Description	3-wheel electric forklift truck
2	Model	TKA10-30	TKA15-30
3	Load capacity Kg	1000	1500
4	Load center mm	500	500
5	Max. lifting height mm	3000	3000
6	Tilting angle(forward- backward) deg	2/4	2/4
7	Free lift mm	0	0
8	Wheel type	Polyurethane solid tire
9	Fork size(LxWxT)mm	92010035	92010035
10	Fork spread mm	545	655
11	Overall length(without forks) mm	1350	1450
12	Overall width mm	870	1100
13	Overall height mast closed mm	2070	2070
14	Overall height fork raised(without backrest) mm	3535	3535
15	Overhead guard height mm	1965	1965
16	Outside turning radius mm	1170	1272
17	Min. intersecting aisle mm	2700	3050
18	Max. walking speeds Km/h	7.2	7.0
19	Lifting speeds (Loaded/ Unloaded) mm/s	125/170	125/170
20	Grade abitity %	8	8
21	Total weight( with battery) Kg	1950	2170
22	Front tire	Φ305*127	Φ305*140
23	Rear tire	Φ267*127	Φ267*127
24	Wheel base(adjustable)mm	880-961	950-1031
25	Ground clearance mm	90	90
26	Service brake	hydraulic
27	Parking brake	mechanical
28	Battery V/Ah	24/360	24/480
29	Charger V/A	24/40	24/50
30	Driving motor Kw	2.8 AC	2.8 AC
31	Lifting motor Kw	3.5	3.5

product picture

Factory details

Our Services

1. One-stop solution service.

2. Customized-service all accepted

3. customer service is in time.

4. free maintence for 1 year.

Any questions please feel freely to contact us!
