Features:
Lifepo4 battery pack
12V 200Ah solar storage li ion battery with lead acid case
Interchange design of lead acid battery
Built-in PCB for over-voltage, under voltage and over-temperature
Series connection up to four batteries (48V)
Internal cell balancing
Maintenance-free
Rugged mechanical design
Thousands of cycles under normal conditions
Can be charged with most lead-acid chargers
Notes:
Our lifepo4 lithium battery pack (12V solar storage li ion battery), with nominal voltage of 12V and capacity of 100Ah is assembled with high quality LiFePo4 cells. It can be used individually and can be connected in serial or parallel to achieve given voltage and capacity.
Specification:
Battery Specification | ||
Item |
Parameters |
|
Model |
IFM12-2000E2 |
|
Material |
LiFePO4 |
|
Nominal Voltage |
12.8V |
|
Nominal Capacity(0.2C) |
200Ah |
|
|
Max. Constant Current |
30A (can be customized) |
Standard Discharge |
Max. Pulse current(10ms) |
60A/3s(can be customized) |
|
Cut-off Voltage |
10V |
|
Charge Voltage |
14.6V |
Standard Charge |
Charge Current |
22A |
|
Charge Time |
approx. 7hrs |
Charge Temperature |
-10~45°C |
|
Discharge Temperature |
-10~60°C |
|
Storage Temperature |
-20~70°C |
|
Cycle life |
2000 times |
|
Housing |
ABS |
|
Size |
260 x 158 x 246mm |
|
*We provide 12 months warranty* | ||
Cell data
Nominal Capacity |
3300mAh(0.5C) |
Minimum Capacity |
3300mAh(0.5C) |
Nominal Voltage |
3.2V |
Battery Weight |
86g |
Inner Resistance |
<40mΩ |
Charging Mode |
CC/CV |
Recommended Charge Current |
0.2C |
Charge Voltage |
3.65V |
Discharge Cut off Voltage |
2.5V |
Max Continues Discharge Current |
3.0C |
Max Pulse Discharge Current (2 Seconds) |
5.0C |
Cycle Life at 1C 100%DOD |
>2000 times |
Charge Temperature |
0~55°C |
Discharge Temperature |
-20~60°C |
Storage Humidity |
<85%RH |
Major applications:
Telecommunications
Cordless phones, cellular phones, transceivers and pagers.
Audio and Video Devices
Digital cameras, Camcorders, Portable DVD, VCD, MD and CD palyers.
Lightings
Emergency lightings, Solar lights, Search lights and Flashlights.
Remote Control Toys
R/C Cars, R/C Ships and Model planes.
Information Devices
Notebook computers, Personal facimile machines, PDAs.
Power Tools
Electric drills, Sanders, Screwdrivers, Saws, Polishers.
Other Applications
Electric bicycles, Shavers, Massagers, Electric tooth brushes, Handheld vacuum cleaners, Handheld terminals.
*We provide 12 months warranty* |
Advantage:
1) Long cycle life
2) Maintenance-free operation
3) Good safety performance
4) Low self-discharge and fast charge
5) Environment friendly
6) High capability and stability
We could produce the battery whose voltage and capacity in variety of model multiples according to client’s requirement.
Share some 12V LiFePo4 battery Module with you.
Main uses:
Large electric vehicle: electric golf carts, buses, electric cars, sightseeing cars and hybrid vehicles
Light electric vehicle: electric bicycle, small flat electric car, forklift, cleaning vehicles, electric wheelchair
Power tools: electric drill, electric saw, lawn mower
Remote control cars, boats, aircraft and other toys
Solar and wind power energy storage equipment
UPS and emergency lights, warning lights, miner's lamp (best safety)
What Applications of our Lithium ion battery packs?
1. Emergency power supply, LED light & flashlight: headlamp, emergency light, solar flashlight, searchlight, lantern, bicycle light, bright flashlight, high-end lamp, military flashlight and so on.
2. Home appliance products: electric vacuum cleaner, eletric sweeper, water meter, gas meter, electrinc children toys, electric warm shoes, electric blancket, TV remote control (RC) and so forth.
3. Consumer applications, communicate & telephone equipment: MPS, tablet PC, laptop, Bluetooth earphone, power bank, portable DVD player, speaker, microphone, sound equipment, audio, digital camera and others
4. Outdoor sports products: camping light, mountain bike light, solar emergency light, self-defense flashlight and that .
5. Electronical tools & electric transportation vehicles: electric bike, electric car. e-scooter, electric motor and all that.
6. Solar lawm, remote control
7. Medical device
8. Backup power supply
About Us
We specialized in LiFePO4 New energy vehicle power Battery, Lithium ion Battery Engine Start Battery, Backup Storage Battery for Communication base stations, solar & wind hybrid energy storage and household energy storage battery system solutions.
How to Maintain Lithium Battery
Lithium batteries are presently the most commonly used energy storage devices on electric bike, electric scooter, golf car, mobile phones, laptops, digital cameras and other electric devices. Learning how to maintain lithium batteries can not only prolong battery lifetime but also protect your device from potential damage.
1. Charge new batteries. It's not necessary to charge over 12 hours when first used. When a device powered by batteries is purchased, sellers will usually tell us the batteries must first be charged 12 hours before using. Actually, this is unnecessary. Unlike common Ni-CD or Ni-MH batteries, most lithium ion batteries are activated before leaving the factory. Due to their low self-discharge, it’s unnecessary to charge lithium ion batteries for such a long time when new. Lithium ion batteries are ready for use when the charger indicates so, and they will reach their best capacity after 3 or 5 cycles.
2. Use appropriate chargers. Many people take great care with their electronic gadgets, but often neglect the consequences of bad chargers on their lithium ion batteries. When choosing a charger, the original charger is the best choice. If that's unavailable, a high quality charger that has an overcharge protection function, or a brand name charger will do. A low quality battery charger can lead to shorter run times, premature battery failure, or even fire or explosion.
3. Avoid frequently over charging. Over charging with a low quality charger may let the battery's interior rise to a high temperature, which is bad for the lithium ion battery and charger. Thus, simply fully charging is good enough - overcharging will make your lithium battery into a little bomb if overcharge protection function is missing.
4. Avoid touching metal contacts. All batteries' contacts need to be kept clean for best performance. When carrying batteries around, do not let the contacts touch metal objects such as keys; this could cause a short circuit, damaging the battery or potentially resulting in a fire or an explosion.
5. Avoid using often in high or low temperature environments. Lithium ion batteries have optimal working and storage temperatures. If they're continually used in extreme temperature environments, this will negatively affect battery use time and useful cycles.
6. Avoid long periods without using or recharging. If batteries will be left unused for 3 months or more, partially recharge them (to around 30-70% of capacity, depending on planned storage time), then store the device to prevent battery damage. You may need to take the device out of storage and charge again after a few months.
What 10 Tips should be note when using Lithium ion battery?
Warnings:
Do not immerse the battery in water or seawater, and keep the battery in a cool dry surrounding if it stands by.
Does not use or leave the battery near a heat source as fire or heater
Use the battery charger specifically for that purpose when recharging.
Do not reverse the position and negative terminals.
Do not connect the battery electrodes to an electrical outlet.
Do not discard the battery in fire or a heater.
Do not short-circuit the battery by directly connecting the positive and negative terminals with metal objects.
Do not transport or store the battery together with metal objects such as hairpins, necklaces, etc.
Do not strike, trample or throw the battery.
Do not directly solder the battery and pierce the battery with a nail or other sharp objects.
