Woodworking Sanding Machine
US$ 10,000 - 16,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Sander
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
MDF/plywood/art Crafts Thickness Sander MachineUS$ 25,000 - 33,000MOQ: 1 Set -
Wood / Plywood Sanding Machine / Sander MachineUS$ 10,000 - 18,000MOQ: 1 Set
-
China Sell!High Quality!Primer Abrasive Machine(sander Equipment)US$ 10,000 - 30,000MOQ: 1 Set
-
Primer Grinding Machine(sander Equipment)US$ 10,000 - 30,000MOQ: 1 Set
-
China Sell!High Quality!Primer Sanding Machine(sander Equipment)US$ 10,000 - 30,000MOQ: 1 Set
Condition
New
Type
Sander
Place of Origin
Guangdong, China
Brand Name
Jixingyuan
Model Number
JXRA-I-1000
Voltage
380v
Power(W)
13kw
Dimension(L*W*H)
1862*1335*2040mm
Weight
1.8T
Certification
CE, ISO9001-2000, CE,ISO 9001:2000
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
primer sander machine / Sanding Machine
- sanding machine is specially designed for lacquer grinding after coating,suitable for all kinds of flat products especially wood and panel, the surface will be uniform and smoothly after grinding.
- sanding machine adopt soft bottom sanding wheel which can grind the rough coating surface to flat and reduce the pressure of panel at the same time .
- sanding machine conveying and grinding of the sanding belt all adopt frequency conversation adjustment system cooperating better and suitable for many products.(uv board, wood, metal, glass, tile, ceramic).
- sanding machine Integration of the whole body and the fire treatment of key area make it more stable.
Technical parameters: Model |
JXR-R-P600 |
JXR-R-P1000 |
JXR-R-P1300 |
Working Width(mm) |
30~600 |
30~1000 |
30~1300 |
Working Thickness(mm) |
2.5~100 |
2.5~100 |
2.5~100 |
Feeding Speed(m/min) |
6~38 |
6~38 |
6~38 |
Belt Size(mm) |
Φ650*1700d |
Φ1020*1700 |
Φ1320*2200 |
Sanding Roll Size(mm) |
Φ190 |
Φ190 |
Φ240 |
Polishing Roll Size(mm) |
Φ190 |
Φ190 |
Φ190 |
Work voltage(mpa) |
>=0.55 |
>=0.55 |
>=0.55 |
Wind Velocity(m/s) |
25~30 |
25~30 |
25~30 |
Convey Power(kw) |
1.5 |
1.5 |
1.5 |
Polishing Power(kw) |
4 |
4 |
7.5 |
Belt Power(kw) |
5.5 |
7.5 |
11 |
Total Power(kw) |
11 |
13 |
18.5 |
Machine Size(mm) |
1300*1000*2000 |
1900*1600*2100 |
2700*2100*2000 |
Machine Weight(kg) |
1600 |
2200 |
3500 |
