sander machine/wood sanding machine /plywood sander machine
(JXR-R-P1300)
Description:
- sander machine is specially designed for lacquer grinding after coating,suitable for all kinds of flat products especially wood and panel
- The surface will be uniform and smoothly after grinding.
- sander machine adopt soft bottom sanding wheel which can grind the rough coating surface to
- flat and reduce the pressure of panel at the same time .
- sander machine conveying and grinding of the sanding belt all adopt frequency conversation adjustment system cooperating better and suitable for many products.(uv board, wood, metal,
- glass, tile, ceramic).
- sander machine Integration of the whole body and the fire treatment of key area make it more stable.
Technical parameters:
Model |
JXR-R-P600 |
JXR-R-P1000 |
JXR-R-P1300 |
Working Width(mm) |
30~600 |
30~1000 |
30~1300 |
Working Thickness(mm) |
2.5~100 |
2.5~100 |
2.5~100 |
Feeding Speed(m/min) |
6~38 |
6~38 |
6~38 |
Belt Size(mm) |
Φ650*1700d |
Φ1020*1700 |
Φ1320*2200 |
Sanding Roll Size(mm) |
Φ190 |
Φ190 |
Φ240 |
Polishing Roll Size(mm) |
Φ190 |
Φ190 |
Φ190 |
Work voltage(mpa) |
>=0.55 |
>=0.55 |
>=0.55 |
Wind Velocity(m/s) |
25~30 |
25~30 |
25~30 |
Convey Power(kw) |
1.5 |
1.5 |
1.5 |
Polishing Power(kw) |
4 |
4 |
7.5 |
Belt Power(kw) |
5.5 |
7.5 |
11 |
Total Power(kw) |
11 |
13 |
18.5 |
Machine Size(mm) |
1300*1000*2000 |
1900*1600*2100 |
2700*2100*2000 |
Machine Weight(kg) |
1600 |
2200 |
3500 |
Package
wooden standard carton is suitable for the export and long transportation,free fumigation.
Payment
We usually accept T/T, payment terms : 30% TT deposit, the balance before shipping.
Shipment
Air,sea and express transportation all are available,we have good cooperations with them ,this saves your shipping cost and guarantee your goods safe, if your own forwarder in China can
help you to handle the export ,we can accept the factory price(EXW.),
We arrange the local shipment,which’s easy for you to control the transportation cost.
Warranty
- 1 years warranty for the machines.
- Any warranty shipping cost to us is responsible by buyer
certification of quality :
pictures of us :
