Heavy putty machine
- 10 Set / Sets per Month
- shanghai
- advanced design easy operation mushroom slice cutting machine
- advanced design easy operation shitake slicer machine
- advanced design easy operation spiral vegetable slicer
- advanced design easy operation automatic vegetable mushroom slicer
- advanced design easy operation multifunctional vegetable cutter
- advanced design easy operation vegetable slicer/mushroom slicer
Product Details
Condition: | New | Brand Name: | JXY | Model Number: | JXFT-II-600 |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Machine Configuration:
1,The machine can be applied to full the putty or coating of a variety of products with surface roughness or texture,making the product much more smooth.The reverse steel roll of this machine could full coating into the sunken places.It can substitute manual filling work but only for those products with light roughness.This machine is suitable for floor,furniture,decorative board,calcium silicate board and so on,which own flat surface.Individually designed reverse-rotation scratching and forward-rotation filling devices could control the filling volume by adjustment of the roller and scraper,suitable for many kinds of paintings,such as NC,PU,PE,AC,UV,etc.This machine is equipped with devices t oprevent spills putty.
2, using imported materials rubber roller diameter of 240mm, the roll surface by CNC precision machining.
3, Putty roll with a diameter of 240mm light big roll, chrome roll surface, cylindrical grinder by CNC precision machining.
4, equipped with imported materials scraper strong toughness, by the reducer adjustment, high accuracy.
5, the conveyor belt is imported materials 3mm, solvent, from the floor to prevent the phenomenon, plus anti-deviation device.
6, running light roller and rubber roller by an independent drive and control gear, wherein the spacing between the adjustment screw through a worm machine, driven dovetail mechanism to complete.
7, the bearing sealing structure to prevent the penetration of paint
8, by two rubber rollers and a putty roll composition greatly increases the amount of padding.
9, the entire machine configuration Taiwan Delta converter and three-phase asynchronous motor worm gear.
10, the whole package, a diaphragm pump, a heating oil tank 20L, a putty funnel.
Customers need to take care of themselves with others:
1,50Hz, 380V three-phase power supply.
Modle | JXFT II-600 | Modle | JXFT II-600 |
working width(mm) | 600 | working thickness(mm) | 2~80 |
shortest working length(mm) | 300 | feeding speed(m/min) | 5~15 |
size of coating roller(mm) | 750×240 | size of doctor roller(mm) | 750×150 |
size of putty roller(mm) | 750×240 | size(mm) | 2100×1260×1580 |
power of putty roller(kw) | 0.75 | zhujing NMRW075-80 series | Delta VFD007M43B frequency converter |
convey power(kw) | 0.75 | zhujiang NMRW075-30 series | Delta VFD007M43B frequency converter |
power of coating roller(kw) | 0.75 | zhujiang NMRW075-60 series | Delta VFD007M43B frequency converter |
power of doctor roller(kw) | 0.37 | zhujiang NMRW050-40 series | Delta VFD004M21A frequency converter |
total power(kw) | 9.74 |
| |
The working of the elevator is controled by worm gearing double swallow tailed grooves. | |||
The feeding side is equipped with infrared probe(optional),avoiding accident arm hurt or over-thickness. | |||
The scraper is made up of high strength tool steel,equipped with NMRW30-50 series speed reducer,to make sure the accuracy of the scraper angle adjustment. |
