Lengthen Dust Cleaning Machine
Specification:
The machine is suitable for dusting all kinds of panel before coating product line and curtain painting or after sanding.
Automatically clean the dust after sanding to improve the coating quality.
The double nylon hair brush with strong blower to achieve powerful dust effect.
Equipped with wire-speed table which can single work or cooperate with working lines.
Importing skid-against conveyor to increase friction for working which can efficiently prevent skidding from the belt.
Technical Parameter:
| Model | JXDC-I 600 | JXDC-I 1300 | JXDC-I 2000 |
| Working Width(mm) | 600 | 1300 | 2000 |
| Convey Power(kw) | 0.75 | 1.5 | 2.2 |
| Fan Power(kw) | 0.55*1 | 0.55*2 | 0.55*3 |
| Hair Brush Power(kw) | 0.75 | 1.5 | 2.2 |
| Hair Brush Size(mm) | Φ180*750mm | Φ180*1450mm | Φ180*2150mm |
| Convey Speed(m/min) | 0~15 | 0~15 | 0~15 |
| Total Power(kw) | 2.05 | 4.1 | 6.05 |
| Machine Weight(kg) | 1800*1300*1600mm | 1800*2050*1600mm | 1800*2750*1600mm |
| Machine Size(mm) | 500kg | 700kg | 900kg |
1. Wooden standard carton is suitable for the export and long transportation,free fumigation.
2. Air,sea and express transportation all are available,we have good cooperations with them ,this saves your shipping cost and guarantee your goods safe, if your own forwarder in China can help you to handle the export ,we can accept the factory price(EXW.), We arrange the local shipment,which’s easy for you to control the transportation cost.
Service:
1,Professional in woodworking machinery Especially in Paint Finishing System and Sanding Machines Series.
2,Supply single set machine as well as whole production lines.
3, Solve all kinds of technical problems and provide professional service.
4,12 Hours online service
About us:
Shenzhen Jixingyuan Technology Joint-Stock Co., Ltd
Established in 2003, Shenzhen Jixingyuan Technology Joint-Stock Co., Ltd. is engaged in the production, sale and service of UV surface&edge coating equipments, such as Roller coaters, UV curing equipments, Curtain coaters, Spraying equipments, Robot series and so on.
Jixingyuan is currently the fastest growing painting equipmet company in China market. it has a good reputation and ambitious development goals. Also own an exzcellent team, keep learning experience of domestic and oversea. Struggle for becoming the leading enterprice in the field of painting equipment.
Our Team:
1. What is the UV coating machine MDF warranty?
Warranty: Warranty is valid for 12 months in the hypothesis of machinery use for an 8-hour
working shift. Warranty does not cover parts subject to normal wear or damaged by improper
use, incident or negligence of the Buyer or by reasons external to normal use (i.e. change in the
power net, caused by thunderstorm, etc.) Transport costs and labour are excluded.
2. Why choose JXY?
1,Professional:We are professional in woodworking machinery field for more than 10 years.
2,Excellent:Our machines get great reputation and produce nice quality product for customers all over the world.
3,Economial:We offer the good price with great quality because we do high-volume production manufacturer.
3.How to contact me?
More details please contact with Jasmine
Skype ID:jasminelovesiki
Shenzhen Jixingyuan Painting Equipment Co., Ltd
Tel:86-755-27539937
Headquarter:19F, Zhongya R&D Building; Songgang Town; Baoan District; Shenzhen
Factory: 10 Block, Jinjiali Industry Zone, Bitou; Songgang Town; Baoan District; Shenzhen
