Furniture panel/floor/glass/metal Curtain Flow Painting Equipment with 600/1300mm UV/NC/PE/PU Water-based Painting Machine
Features:
- For coating all kinds of flat products (such as wood, plastic, metal, solar glass, etc.) , or a little concave-convex products.
- This machine has high working efficiency and low waste of painting.
- Curtain head adopts two-direction adjustable structure which can adjust clamp stroke between 0-100mm.
- This machine is suitable for all kinds of paint such as UV, PU, NC, PE paint which the paint can recycle.
- The convey belt is imported 3mm PU materials which can resistant solvent and avoid seam. The bottom of convey belt is weighted which can adjust the speed by inverter and no vibration.
- Designed dustproof can avoid curtain drifting and dust.
- Equipped a large capacity oil tank with electronic control constant temperature and oil pump which have better filter effect and stable flux.
| Model | JXLV-600 | JXLV-1300 |
| Working Width(mm) | 600 | 1300 |
| Working Thickness(mm) | 2~80 | 2~80 |
| Shortest Working Length(mm) | 300 | 300 |
| Coating Thickness(s) | 7~15s adjustable | 7~15s adjustable |
| Feeding Speed(m/min) | 5~50 | 5~50 |
| Convey Motor | Horizontal type gear reducer motor gear reducer | Horizontal type gear reducer motor gear reducer |
| Convey Motor Power(kw) | 0.75 | 2.2 |
| Pump Motor Power(kw) | 0.75 | 0.75 |
| Oil Tank Heating Rods Power(kw) | 6*2 | 6*2 |
| Total Power(kw) | 13.5 | 14.95 |
| Machine Weight(kg) | 530 | 730 |
| Machine Size(mm) | 3000*1240*1100 | 5000*1940*1100 |
1. Wooden standard carton is suitable for the export and long transportation,free fumigation.
2. Air,sea and express transportation all are available,we have good cooperations with them ,this saves your shipping cost and guarantee your goods safe, if your own forwarder in China can help you to handle the export ,we can accept the factory price(EXW.), We arrange the local shipment,which’s easy for you to control the transportation cost.
Shenzhen Jixingyuan Technology Joint-Stock Co., Ltd
Established in 2003, Shenzhen Jixingyuan Technology Joint-Stock Co., Ltd. is engaged in the production, sale and service of UV surface&edge coating equipments, such as Roller coaters, UV curing equipments, Curtain coaters, Spraying equipments, Robot series and so on.
Jixingyuan is currently the fastest growing painting equipmet company in China market. it has a good reputation and ambitious development goals. Also own an excellent team, keep learning experience of domestic and oversea. Struggle for becoming the leading enterprise in the field of painting equipment.
Our Team:
1. What is the UV coating machine MDF warranty?
Warranty: Warranty is valid for 12 months in the hypothesis of machinery use for an 8-hour
working shift. Warranty does not cover parts subject to normal wear or damaged by improper
use, incident or negligence of the Buyer or by reasons external to normal use (i.e. change in the
power net, caused by thunderstorm, etc.) Transport costs and labour are excluded.
2. Why choose JXY?
1,Professional:We are professional in woodworking machinery field for more than 10 years.
2,Excellent:Our machines get great reputation and produce nice quality product for customers all over the world.
3,Economial:We offer the good price with great quality because we do high-volume production manufacturer.
3.How to contact me?
More details please contact with Jasmine
Skype ID:jasminelovesiki
Shenzhen Jixingyuan Technology Joint-Stock Co., Ltd
Tel:86-755-27539937
Headquarter:19F, Zhongya R&D Building; Songgang Town; Baoan District; Shenzhen
Factory: 10 Block, Jinjiali Industry Zone, Bitou; Songgang Town; Baoan District; Shenzhen
