Specifications
surface mounted, 5 minutes'installation ,wireless solution, IP68 ,accuracy>97%,10 years life span, low maintenance,high qualityROSIM Wireless Vehicle Detctor, Wireless Solution!
Patent Design! Factory Price! High Quality!
Excellent Sales Service and Techinical Support !
Product Description
Wireless Vehicle Detector (WVD) is based on magnetometer, short range RF and nano power communication protocol technology. It is installed onto the road surface to collects the data of traffic flow. The data is gathered by Wireless Access Point (WAP), which acts as a wireless gateway between the wireless vehicle detection system and other traffic application systems. All the WVDs, under the management of WAP, establish a local wireless sensor network, which collects traffic information real timely.
Major advantages:
a) Install fast. It is only almost 6 minutes that is needed to install one wireless vehicle detector in the road, after installation, the traffic control could be released immediately;
b) Work all-weather. Bad weather for example heavy fog, snow and rain makes no difference;
c) No damage to the road. There’s no need to cut slots on the road surface and place cables or wires as the installation of loops, but only a tiny hole with the size Φ 120/H 100 mm, which makes WVDs become the most suitable vehicle detecting solution on the city high-way and bridges;
d) About 10 years long life span. With high standard water proof and anti-press characteristics, WVD wireless vehicle detector can even be used in the damaged or distorted roads where loops cannot be installed.
e) Cost saving. You just can use the cement which is about $2 for 3-4 sensors.
f) Easy to maintain. Unlike the loops that are easily to be damaged but difficultly to be repaired, WVD wireless vehicle detector supports firmware updating over the air. No need to re-cut the slots, no more materials needed, and all of what you need is to take almost 10 minutes for the devices wireless updating;
g) Low operation consuming. Due to the ultra-low power design and battery supply solution, WVD wireless vehicle detector’s consumed power is very lower than any other detectors like loops, video, micro-wave etc. in the market. This appears more and more significantly to our environments;
h) Replace loops seamlessly. The same installation position and compatible output signals makes it easily and simply to replace loops in your system directly.
Functions of Detector
a) Vehicle counting b)Vehicle move direction measurement
c) Average vehicle speed measurement d)Queue detection
How does it work?
By capture the tiny change of magnetism caused by the passing vehicle, WVDs (Wireless Vehicle Detector) calculate the vehicle velocity, length, type and occupy rate rapidly, and then send these information to the WAPs (Wireless Access Points), which will receive all the on line WVDs’ information and transmit these data to the user systems through RS-232/485, Internet, GPRS, etc..
Application:
Installation
In the application of traffic signal controlling, traffic flow monitoring, traffic guiding, speed enforcement and red light enforcement, the installing place of the wireless vehicle detector (WVD) is the same as loops. The installation and signal connection of wireless access point (WAP) is compatible to loop controller, see following figure of wireless vehicle detection system.
Certifications
Maintenance and Support :
Rosim ITS provides our customers high quality wireless vehicle detecting products and solutions, all the products support wireless updating, which makes it easily
maintained. Also, Rosim ITS provides 24 hours on-line supports .
Thanks for your attention! What we can do is more than that!
So any other applications or ideas from you are welcomed!
After reading this, if you have any questions or want more info documents, plz contact Rebecca now!
1. You can email her to any email address in the following;
2. You can add her SKYPE( rebecca.ou6),Yahoo Messeger( rebeccaou88) or Whatsapp for requiring more info documents;
3. You can directly call her ( 00 86 13286315270).
Any way is welcomed! We will be waiting for you anytime!
