Specifications
accuracy>99% wireless solutionsmall size 2mimutes installation
cost saving replacing ultrasonic
Rosim Wireless Parking Space Detection System:
ROSIM's parking system include wireless parking space detector and wireless parking data collector;this system monitors the occupancy of vehicles in indoor/outdoor parking lot, each parking space is installed a wireless parking space detector which feeds back occupancy information to parking data collector. Therefore,the real-time parking occupany information can be stored in a data collector for statistical analysis and then it will be uploaded to an online server of external access for car park owner to improve the efficiency of the car park so that parking utilization and enforcement efficiency are optimized.
Product Information
ROSIM wireless Parking Space Detectors, which are installed in each individual parking space, measure occupancy of these parking spaces. Due to the wireless sensor network formed among these Parking Space Detectors, wireless routers and one data collector in a certain parking lot, the parking space occupancy information is transmitted to system provider’s parking management platform timely.
Specification:
Rosim learns from many failed cases in the world and has done so many experiments to ensure the high accurancy. We use wireless vehicles detectors with technology of magnetic and optic to be a core part of our Data Acquisition System, combined with Data transmission System which includes router and data collector, Central Management system and Data Dissemination System to realize Urban Parking Guidance System with high accurancy rate. This system is helpful to establish a healthy and harmonious traffic system.
Applications:
The ROSIM wireless parking detection network provides system integration accurate measurement on occupancy of individual parking spaces. This information can be used to parking management system, traffic and indoor/outdoor parking guidance, on-street parking enforcement and overstay detection.
The Schematic plot of system:
Major advantages:
1) Wireless communication: there’s no need to place cables or wires as the installation of loops or ultrasonic sensor, but only pad, which makes WPSDs become the most suitable vehicle detecting solution for parking lot, especially outdoor parking lot;
2)High accuracy: the ROSIM wireless Parking Space Detector featured with dual magnetic and optic detection technology. The combination of the two vehicle detection technology, as well as a sophisticated algorithm, greatly improves the accuracy and efficiency of the detection. accuracy>99%
3)Fast installation: it just needs about 2 minutes for installation of each WPSD because of the adoption of pad installation;
4)work in all weather: Because the WPSD has strong characteristics of waterproof, snow defense, anti-press, anti-corrosion and strong anti-jamming capacity,it can normally work in all weather;
5)Average 3 years life span( replaceable);
6) Easy to maintain: Wireless parking space vehicle detector (WPSD) supports firmware updating over the air.
7) Low operation consuming: due to the ultra-low power design and battery supply solution, Wireless parking space vehicle detector (WPSD) ’s consumed power is very lower than any other detectors in the market. This appears more and more significantly to our environments;
Installation:
Maintenance and Support
Rosim ITS provides our customers high-quality wireless vehicle detecting products and solutions, all the products support wireless updating, which makes it easily maintained, and 1 year quality guarantee .
