Specifications
cnc router for styrofoam 2040big mold
solid wood process and three sculpture with big size
0.05 reposition accuracy
CNC Router for Styrofoam RJ2040
Features
The machine is specially designed for the engraving of Polystyrene, PS Styrofoam, and Foamer.
Because the machine is very big, so we calculated strictly the movement stability and transportation, after stabilized after high temperature, we made the body as separated two parts and connected by hinged bolt.
The whole body is supported by 16 adjustable legs which makes the high stability.
The table is jointed with HT200 cast iron board with 40mm thickness.
Spindle is Italy 6.0KW water cooling. Low rotation and high torque.
Transmission we use H30 square rails and helicalrack.
Japan Yaskawa 850W servo systems and 1:5 reducer. High precision helicalrackand the reducer make movement fast, stable, and high accuracy. It is ideal middle size PS machine.
Application
Big mold
Solid wood process and three sculpture with big size
Parameters
Description |
RJ 2040 |
Working Area (X * Y * Z) |
2000×4000×1250mm |
Reposition Accuracy |
0.05 |
Traveling Speed |
80000mm/min |
Spindle Power |
HSD6KW, Water Cooling (Domestic Spindle Optional) |
Tool holder Diameter |
φ32 φ25 |
Net Weight |
7500KG |
