Specifications
12year of R&D
22agent in world
5000event experiences
1st company self-conducting 3D directional testing and GLL data in China
line array subwoofer audio system audio equipment
Proaudio, Loudspeaker, professional peaker, line array speaker, PA speaker, outdoor speaker, subwoofer, small speaker, active speaker, self-power speaker, powered speaker, amplifier, professional amplfier, Disco speaker, chuch speaker, switching power amplifier, transformer amplifier, mainly designed for live performance, stadium, outdoor use, fixed installation.
| TECHNICAL SPECIFICATION | |
| Frequency Response: | 38Hz-200Hz(±4dB) 25Hz-320Hz(-10dB) |
| Nominal Coverage: | Omnidirectional |
| Sensitivity (@1w/1m): | 102dB SPL (40-200H) SPL |
| Power Rating (AES): | 1200W |
| Nominal Impedance: | 8Ohm |
| Maximum SPL: | 133dB(continuous) 139dB(peak) |
| Drivers: | 2*15"(75mm voice coil)woofer |
| PHYSICAL DATA | |
| Dimension (H*W*D): | 605*700*700mm |
| Weights: | 65kg |
| Connectors: | 2*WP4 connectors |
| Speaker Cables: | 1-2+ |
| Materials: | 18mm birch multi-plywood splints |
| Finish: | Black water envirimental elastically paint |
| Grille: | Black epoxy mesh grille with acoustically reticulated cloth |
| Rigging: | 0 degree adjustable |
VCS Woofer is recommanded to fly with VCM, Dual 10" compact line array for friendly use.
Applications:
Large-scale touring performance.
Stadium or gymnasium
Features:
Soft and low frequency elastic
Long stroke high power LF driver
Small volume, vented, horn preposition design
4.Our line array speaker have their own EASE FOCUS data and GLL data, You can analog the angle with EASE FOCUS software. Welcome to download the software and data from our website: /en/down/index.asp?gdstype=1435
| MOQ: | 1PCS |
| Sample led time | 3 days |
| Mass order | 1-2 weeks |
| Packting detail | Carton : 510*400*700 mm |
| 1 Piece in a carton | |
| N.W. : 25KG ; G.W. 28KG | |
| Delivery Clause | EXW Factory, FOB Guangzhou |
| Terms of payment | T/T;L/C;Westerm Union; Cash |
1) Global leading professional Manufacturer of professional speaker and amplifier.
2) Product quality: Superior speaker and amplifier, top technology and quality.
3) Certificate: CE,RoHS,GS,SGS,ISO9001
4) Monthly Production Capacity: 2000pcs
5) Fast delivery: Get your order when you need it.
6) 4000 square meters workshop, with about 200 workers and 20 professional engineers
7) Convenient Transportation: 1 hour to Baiyun Airport
8) 24 hours on line service.
