Ocean OC-513V High Speed Transfer Cheap Wifi HD 960P IP Camera CCTV Bullet IP Network Camera

IP CAMERA

Model

IPS-513V

IPS-613V

IPS-1013V

Item

Device Type

960P  AR0130 CMOS sensor

720P OV9712d

CMOS sensor

1080P Sony

MX122

CMOS sensor

Size

1/3

1/4

1/2.5

Day and Night

Yes

Min.Scene  Illumination

0.01lux(IR ON)

0.5lux(IR ON)

0.01lux(IR ON)

Infrared sensitivity

Support

IR Filter

IR-CUT

IR-led lamp

48pcs

IR distance

50M

Electronic shutter

1/5-1/15,000 /S

lens

2.8-12MM

Focus

Auto zoom

Aperture

Fixed Aperture F1.2

Video

Yes

Yes

Yes

Compression

H.264 Main Profile

  Picture Resolution

1280*960@30fps   1280*720@30fps

1280*720@30fps

1920*1080@30fps

Steam flow

Support dual stream

Bit Rate

128-8192kbps

Bit Rate Type

CBR/VBR

S/N Ratio

>50DB

Image enhancement

Auto White Balance,Backlight compensation,Brightness,Contrast,Saturation adjusted

Subtitles input

Support channel name, date/time

Flip Config

Up/down, Left/right

Audio

Support the microphone input andAudio output, support two-way voice intercom equipment

equipment

An external audio equipment

Audio input/ output

one channel audio input, one channel audio output

Audio  Compression

G.711/G.726

Alarm input/output

Alarm way

Motion Detection:Configure motion detection area,detecting sensitivity is adjustable

Alarm processing

The control center to monitor, Send E-mail,FTP,  Log record,SD card storage etc.

Network

Protocal

HTTP,TCP/IP,UDP,SMTP,DDNS,DNS,SNTP,DHCP,FTP,RTP,RTSP,UPNP,ONVIF,28181

Ethernet

Ethernet (10/100 Base-T),RJ-45 connector

Safety

IP address filtering,User level password protection,The user access log

Wifi protocol

Encryption

Software

WEB Browser

       Microsoft Internet Explorer 6.0 and above,google,firefox etc.

Mobile Phone

Support iPhone,Android,Bit rate:32K – 512K adjustable,Frame rate:6–12 fps

Software Management

CMS and the devices Compatible with ONVIF

Software intelligence function

Motion detection,Miss object detection, Moving object tracking, counting, Retrograde motion detection, etc.

Event action

Files are stored to the back end equipment,Send E-mail,Send SMS,Zoom in alarm,

Remote Access

DDNS,Software,P2P

Physical properties

Accessories

Power adapter, CD, Screw bag

Power Comsumption

           DC 12V ,Module power consumption is less than 2 W

Temperature

-20°~60°C

Humidity

-10~85%

Weight

Dimension

Certification

CE ,FCC
