SC/PC Optical Fiber Field Splice Connector
US$ 0.9 - 1.6
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Unikit Optical Technologies
Model Number:
RSC250PLW Fiber Optic Connector
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
FTTH SC/UPC Optical Fiber ConnectorNegotiableMOQ: 100 Pieces -
SC/PC Optical Fiber Mechanical ConnectorUS$ 1 - 2MOQ: 100 Pieces
-
SC/UPC Optical Fiber ConnectorNegotiableMOQ: 100 Pieces
-
FTTH SC UPC/APC Fiber Optic Field Assembly Fast ConnectorUS$ 1.1 - 1.9MOQ: 100 Pieces
-
Fiber Optic SC/UPC Field Assembly Fast ConnectorUS$ 1 - 2MOQ: 100 Pieces
Place of Origin
Jiangsu, China
Brand Name
Unikit Optical Technologies
Model Number
RSC250PLW Fiber Optic Connector
Specifications
1 SC/UPC Optical Fiber Field Splice ConnectorSC/PC Optical Fiber Field Splice Connector
Operation Video:
/watch?v=lcRitwp0DQA
/watch?v=EmUgU2Vaquc
Technical specification
Item |
Parameter |
|
Cable Scope |
3.0 x 2.0 mm Bow-type Drop Cable/2.0-3.0mm round cable |
|
Fiber Diameter |
125μm ( 652 & 657 ) |
|
Coating Diameter |
250μm |
|
Mode |
SM/MM |
|
Operation Time |
about 15s(exclude fiber presetting) |
|
Insertion Loss |
≤ 0.30dB(1310nm & 1550nm) |
|
Return Loss |
≤ -45dB |
|
Success Rate |
>98% |
|
Reusable Times |
>10 times |
|
Tensile Strength |
>5 N |
|
Tighten Strength of Naked Fiber |
>10 N |
|
Temperature |
-40~+85°C |
|
On-line Tensile Strength Test (20 N) |
IL ≤ 0.3dB |
|
Mechanical Durability(500 times) |
IL ≤ 0.3dB |
|
Drop Test(4m concrete floor, once each direction, three times total) |
IL ≤ 0.3dB |
|
