Optical Connector
Operation video:
/watch?v=n7hUkr5QmJs
/watch?v=EmUgU2Vaquc
Description
1. Twin end-face of pre embedded fiber is polised in the factory..
2. Fiber optics is aligned in V-groove through the ceramic ferrule.
3. Side cover design provide complete preservation of the matching liquid.
4. Ceramic ferrule with pre-embedded fiber is polished to APC.
5. Length of the FTTH cable is controllable
6. Simple tooling, easy operation, portable style and reusable design.
Item |
Parameter |
|
Cable Scope |
3.0 x 2.0 mm Bow-type Drop Cable |
|
Fiber Diameter |
125μm ( 652 & 657 ) |
|
Coating Diameter |
250μm |
|
Mode |
SM |
|
Operation Time |
about 15s(exclude fiber presetting) |
|
Insertion Loss |
≤ 0.25dB(1310nm & 1550nm) |
|
Return Loss |
≤ -45dB |
|
Success Rate |
>98% |
|
Reusable Times |
>10 times |
|
Tensile Strength |
>5 N |
|
Tighten Strength of Coating |
>10 N |
|
Temperature |
-40~+85°C |
|
On-line Tensile Strength Test (20 N) |
IL ≤ 0.3dB |
|
Mechanical Durability(500 times) |
IL ≤ 0.3dB |
|
Drop Test(4m concrete floor, once each direction, three times total) |
IL ≤ 0.3dB |
|
In stock,ready to go!
Skype: sffiltech007
E: sales2[a]
Send Inquiry to This Supplier
