monitor with speakers 15"
CM15 is a coaxial bi-amp vented speaker, mainly designed for all kinds of touring performances, as well as various fixed installations. CC15 is recommended to use as front stage monitor, live band feedback, and main speaker for small shows even big performance front fill. CC15 is built-in two presets as main speaker and feedback, and needs to match M44 DSP.
The enclosure consists of a 15″ LF driver and a 75mm composite aluminum diaphragm HF compression driver. The voice coil of LF driver is 75mm, and the speakerframe is made of aluminum. The coverage of the HF horn is 80°.
Feature:
·Coaxial structure, to optimise acousitcal image
·HF driver preposition design to get smooth frequency response
·3 inch neodymium HF driver(75mm voice coil)
·Customized high-transient response )75mm vocie coil )woofer
Applications:
·Touring performance
·Stage Monitor
·Theatre
| TECHNICAL SPECIFICATION | |
| FREQUENCY RESPONSE: | 60 Hz ~ 16 KHz (±3 dB ) 45 Hz ~ 18 KHz (-10 dB ) |
| NOMINAL COVERAGE (-6dB): | 80°(H) 80 ° (V) Constant directivity |
| SENSITIVITY(@1w/1m): | 100dB SPL |
| POWER RATING (AES): | 450W |
| NOMINAL IMPEDANCE: | 8 Ohm |
| MAXIMUM SPL: | 126dB (continuous), 132 dB ( peak) |
| DRIVERS: |
LF 1×15" (75mm voice coil woofer HF 1×3" (75mm voice coil) compression driver |
| PHYSICAL DATA | |
| DIMENSIONS(H x W x D): | 598 x438 x 476mm |
| WEIGHT: | 29kg |
| CONNECTORS: | 2 x NL4MP Neutrik Speakon connectors |
| SPEAKER CABLES: | 1+1- |
| MATERIALS: | 18mm birch plywood |
| FINISH: | Black water paint |
| GRILLE: | Black epoxy mesh grille with acoustically reticulated foam |
1) Global leading professional Manufacturer of professional speaker and amplifier.
2) Product quality: Superior speaker and amplifier, top technology and quality.
3) Certificate: CE,RoHS,GS,SGS,ISO9001
4) Monthly Production Capacity: 2000pcs
5) Fast delivery: Get your order when you need it.
6) 4000 square meters workshop, with about 200 workers and 20 professional engineers
7) Convenient Transportation: 1 hour to Baiyun Airport
8) 24 hours on line service.
