karaoke loudspeaker personal loudspeaker 12 inch stage monitor
M12 is a bi-amp vented enclosure, mainly designed as a stage monitor speaker for tour performance, as well as various kinds of fixed installations.
The enclosure consists of a 12″ LF driver and a 75mm composite aluminum diaphragm HF compression driver. The voice coil of LF driver is 75mm, and the speakerframe is made of aluminum. The coverage of the HF horn is 60°--40°. The rotatable horn allows the near-ceiling mounting and aiming easy in the venues with restricted height. M12 provides 4 pcs flying tracks used for fixed installations or hanging and angle modulation in touring performance. The enclosure is configured with a 35mm poles and speaker stands at the bottom.
Feature:
Asymmetrical rotatable horn
Large-size neodymium HF driver(75mm voice coil)
Customized high-transient response woofer(7mm voice coil)
Applications:
Touring performance
Stage Monitor
Theater,music hall
| TECHNICAL SPECIFICATION | |
| Frequency Response: | 65Hz-16KHz(±3dB) 55Hz-18KHz(-10dB) |
| Nominal Coverage: | 60°(H)40°(V)Constant directivity |
| Sensitivity (@1w/1m): | 98dB |
| Power Rating (AES): | 400W |
| Nominal Impedance: | 8Ohm |
| Maximum SPL: | 124dB (continuous)130dB (peak) |
| Drivers: |
LF 1*12”(75mm voice coil)woofer; HF 1*3”neodymium compression driver |
| PHYSICAL DATA | |
| Dimension (H*W*D): | 600*366*333mm |
| Weight: | 22kg |
| Connectors: | 2*NL4MP Neutrik Speakon connectors |
| Speaker Cables: | 1+1- |
| Materials: | 18mm,24mm birch multi-plywood |
| Finish: | Black water paint |
| Grille: | Black epoxy mesh grille with acoustically reticulated foam |
1) Global leading professional Manufacturer of professional speaker and amplifier.
2) Product quality: Superior speaker and amplifier, top technology and quality.
3) Certificate: CE,RoHS,GS,SGS,ISO9001
4) Monthly Production Capacity: 2000pcs
5) Fast delivery: Get your order when you need it.
6) 4000 square meters workshop, with about 200 workers and 20 professional engineers
7) Convenient Transportation: 1 hour to Baiyun Airport
8) 24 hours on line service.
