Home > Lights & Lighting > LED Interior Lighting > LED Down Light > 20W Samsung SMD LED Rectangular Shopfitter

20W Samsung SMD LED Rectangular Shopfitter

Name: 20W Samsung SMD LED Rectangular Shopfitter
Brand: NGE or OEM
SKU: 128537377

20W Samsung SMD LED Rectangular Shopfitter thumbnail-1

20W Samsung SMD LED Rectangular Shopfitter photo-1

US$ 39.5 - 67.6 MOQ: 10 Pieces

Key Specifications

Get Latest Price

LED Light Source:

Samsung SMD 5630

Warranty(Years):

3 years

Input Voltage(V):

AC100~240V, 50-60Hz

Contact Supplier Request Quote Chat Now

Shenzhen NGE Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen Hong Kong

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

LED Light Source Samsung SMD 5630

Warranty(Years) 3 years

Input Voltage(V) AC100~240V, 50-60Hz

Lamp Power(W) 20

Lamp Luminous Flux(lm) 1800±100LM

Lamp Luminous Efficiency(lm/w) 85

Color Temperature(CCT) Other, 3000-3500K,4000-4500K,5500-6500K

Working Temperature(℃) -40, 60

Working Lifetime(Hour) 35000

Lamp Body Material Other, Aluminum alloy and tempered glass

IP Rating Other, IP22

Certification CE, C-tick, EMC, LVD, SAA

Model Number NGE-SMD01-RD20W

Place of Origin Guangdong, China

Brand Name NGE or OEM

Specifications

LED rectangular Shopfitter:
1. 20/28/38/48/60W
2.Replace Metal Halide shop light
3. Samsung SMD,CRI>83
4.CE,RoHS,SAA,C-Tick

20W Samsung SMD LED rectangular Shopfitter

Product Features of 20W Samsung SMD LED rectangular Shopfitter:

1. High Lumen Samsung LED, complete lighting >85lm/w, CRI>83.

2. Excellent Driver wide AC100V~240V, PF>0.95, low THD<15%.

3. Ultra-low light degradation in full compliance with U.S.Energy Star requirements, L70>35,000hrs.

4. Good thermal structure design, lifespan last longer than 35,000hrs.

5. Dimmable and emergency version available for choice.

6. 3 years warranty, CE, RoHS, SAA approved.

7. Direct replacement for Philips rectangular downlight HIT-DE MBS200,QBS200,SBS200.

Product Pictures for 20W Samsung SMD LED rectangular Shopfitter:

Technical Parameters for 20W Samsung SMD LED rectangular Shopfitter:

Product Name	LED rectangular downlight
Item Number	NGE-SMD01-RD20W
Rated Power	20W
Input Voltage	AC100-240V, 50-60Hz
Power Factor	>0.95
LED Type	Samsung SMD LED
Luminous Flux	1800±100LM
Color Temperature	3000-3500K,4000-4500K,5500-6500K
CRI	Ra>83
Beam Angle	100°
Product Size	240145136mm
Cutout	227*130mm
Main Materials	Aluminum alloy and tempered glass
Working Temperature	-40~60°C
Lifetime	>35,000hours
Warranty	3 years
Certificate	CE,RoHS,SAA,C-Tick

Test Report for 20W Samsung SMD LED rectangular Shopfitter:

Production pictures for Samsung SMD LED rectangular Shopfitter:

Packing information for Samsung SMD LED rectangular Shopfitter:

Series Products for Samsung SMD LED rectangular Shopfitter:

Item No.	Watt	Input Voltage	Lumens	Size	Cutout	PF
NGE-SMD01-RD20W	20	AC100-240	1800±100LM	230145136mm	227mmx130mm	>0.95
NGE-SMD01-RD28W	28	AC100-240	2400±100LM	230145136mm	227mmx130mm	>0.95
NGE-SMD01-RD38W	38	AC100-240	3200±100LM	230145136mm	227mmx130mm	>0.95
NGE-SMD01-RD48W	48	AC100-240	4000±100LM	230145136mm	227mmx130mm	>0.95
NGE-SMD01-RD60W	60	AC100-277	5000±100LM	230145143mm	227mmx130mm	>0.95

NGE Technology Limited is a professional indoor LED lighting manufacturer and solutions provider.

We are specialized in the LED shop lighting, office Lighting, commercial lighting, LED industrial lighting and residential lighting research and manufacture. Especially, LED shop light, LED tube, LED Panel light, L ED downlight, LED high bay, LED floodlight and LED bulb products are most popular products for us.

NGE Technology owns more than 180 experienced workers,15 persons' R&D team and 8000 square workshop. It is equiped with auto SMT machines, reflow-soldering machine, integrating sphere, goniophotometers machine and inspection instruments, etc.

NGE Technology endeavors to develop new LED lighting products. Our expert R&D team have abundant knowledge of electronic technology, structure technology, thermal management as well as optics design. Almost all of our products are CE certificated and RoHS compliant, and our LED Shop light are UL, PSE, SAA and C Tick approved.

NGE Technology has an excellent overseas sales and after-sales team. NGE products are very popular in Europe, America, Australia, Japan, Middle East and Southeast Asia market now.

We have successfully achieved over 50% annual growth in the turnover in the past 3 years. The turnover in 2012 is estimated to be 12 million US dollars. Let's work together to devote to the new, green and eco-friendly cause for the world.

Welcome to visit .
