CKG 245A CNC pipe lathe , thread processing, threaded pipe processing

FOB Price

USD $20,000 - $50,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Horizontal
CNC or Not	CNC	Automatic Grade	Automatic
Max. Swing Diameter	800mm	Place of Origin	Shandong, China
Brand Name	HAISHU	Model Number	CKG245A
Voltage	380v 50hz	Power(W)	11KW
Dimension(LWH)	3600(18501900	Weight	5800KG
Certification	CE TUV ISO	After-sales Service Provided	Engineers available to service machinery overseas

CKG 245A CNC pipe thread lathe

Max swing diameter: Φ800 mm

Maximum turning length: 1000~10000 mm

Maximum processing outside diameter of pipe:φ245 mm

Spindle bore: φ250 mm

Number of spindle speeds: Servo Promise

Spindle speed: 0~500 rpm

X/Z Servo motor torque: 10/22 N.m

Chuck form: Four-jaw chuck

Turret form: 240*240 4-station ,Vertical

X/Z Rapid traverse: 3/4 m/min

Tailstock quill diameter: φ100 mm

Tailstock quill stroke: 250 mm

Tailstock sleeve taper: MT5

Spindle center to the height of the rail: 410 mm

Main motor: Servo motor 11KW 3000r/min

Machine weight: 5800(L=1000)Kg

Machine outline size (L × W× H): 3600(L=1000)×1850×1900 mm

CNC system: KND/GSK/Siemens/(Optional)

Max swing diameter	Φ800 mm
Maximum turning length	1000~10000 mm
Maximum processing outside diameter of pipe	φ245 mm
Spindle bore	φ250 mm
Number of spindle speeds	Servo Promise
Spindle speed	0~500 rpm
X/Z Servo motor torque	10/22 N.m
Chuck form	Four-jaw chuck
Turret form	240*240 4-station ,Vertical
X/Z Rapid traverse	3/4 m/min
Tailstock quill diameter	φ100 mm
Tailstock quill stroke	250 mm
Tailstock sleeve taper	MT5
Spindle center to the height of the rail	410 mm
Main motor	Servo motor 11KW 3000r/min
Machine weight	5800(L=1000)Kg
Machine outline size (L × W× H)	3600(L=1000)×1850×1900 mm
CNC system	KND/GSK/Siemens/(Optional)
