Home > Manufacturing & Processing Machinery > Machine Tools > Milling Machine > VM1890 Vertical Cnc Milling Machine With ce

VM1890 Vertical Cnc Milling Machine With ce

Name: VM1890 Vertical Cnc Milling Machine With ce
Brand: HaiShu
SKU: 128513133

VM1890 Vertical Cnc Milling Machine With ce thumbnail-1

VM1890 Vertical Cnc Milling Machine With ce thumbnail-2

VM1890 Vertical Cnc Milling Machine With ce thumbnail-3

VM1890 Vertical Cnc Milling Machine With ce photo-1

VM1890 Vertical Cnc Milling Machine With ce photo-2

VM1890 Vertical Cnc Milling Machine With ce photo-3

US$ 50,000 - 150,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

HaiShu

Contact Supplier Request Quote Chat Now

Taian Haishu Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Shandong, China

Brand Name HaiShu

Model Number VM1890

Type Horizontal

CNC or Not CNC

Voltage 380V 50Hz

Power(W) 15/18.5kw

Dimension(L*W*H) 4600x3600x3300

Weight 12500kg

Certification CE ISO9001

Warranty 1 Year

After-sales Service Provided Engineers available to service machinery overseas

VM1890 vertical cnc milling machine

Main specifications

items	name	unit	number
Workbench	Workbench size	mm	2000×900
	T Slots	mm	5×22
	Maximum load bearing	Kg	1600
travel	Moving range X,Y,Z	mm	1800×900×700
	spindle nose to work table	mm	160~860
	distance between spindle center to column	mm	960
feed	Fast moving speed X,Y,Z	m/min	18,18,15m/min
feed	Cutting feed speed X,Y,Z	mm/min	2.5~10000mm/min
spindle	Taper of spindle		BT50
	Spendle speed	r/min	40~4000rpm
	Spendle power	kw	15/18.5
Precision	Positioning accuracy	mm	X:0.032 Y/Z:0.025
Precision	Repeat Positioning accuracy	mm	X:0.018 Y/Z:0.015
machine	size	mm	4600×3600×3300
machine	weight	Kg	12500

Standard configuration:

1.cnc system: FANUC 0i MD

2.Main motor: Japanese FANUC 15/18.5 servo motor;

3.Feed motor: Japanese FANUC servo motor

4.Spindle: high speed and high precision spindle unit of Taiwan 6000rpm, taper BT50

5.Taiwan precision ball screw

6.Prevention and protection of stainless steel in the half

If you are interested in high quality VM1890 vertical cnc milling machine , welcome to leave a message or send the inquiry to understand the details of machine.
