| Packaging Details: | Packing Type: 1unit(s) /ctn.; Packing Dimension: 590x590x210mm Packing Weight: 14.1kg /31.11lbs |
| Packing way: | Standard Export Carton with foam inside suitable for long-distant ocean shipment and tough handling |
| Delivery Detail: | Within 20 Workdays |
80w-250w 110lm/w Mean well/ Inventronics driver 5 years warranty led high bay lighting
CREE XT-E/XP-L CHIPS
MEANWELL/INVENTRONICS DRIVER
1.We really do R&D with the most talented and experience know-how engineers of LED industry.
2.We have completed equipments to produce the outdoor lights.
3.We can supply top quality LED lighting with best possible price Ratio.
4.We support our clients with our unique product and non-stop innovation.
5.We have the most flexible solutions for outdoor lighting.
6.We will always be honest to our clients, do what we can do and do it well.
Obtain Obvious Advantages, Provide Best Price, Welcome to Talk More.
Overview
Everlite led high bay light EL-HB06 is welcomed by customers for its bright lighting, good heat dissapation capacibility and energy saving ability.
Customers in industrial and warehousing applications are constantly looking for ways to reduce the amount of energy required to light their facilities.The E-BEI Series Led High Bay luminaire can driectly replace 250 and 400w HID hig-bays, thereby generating significant energy savings.
When there is a power failure, downtime is reduced with E-BEI LED Highbay , as it turns on instantly, compared to the slow run-up of HID lamps.
The luminaire comes with high-quality optics, ensuring excellent lighting performance in different application areas.
The High-rack opyics are specially designed to illuminate vertical planes in warehouses. With a choice of mounting methods, installation is easy and secure.
- Metal Tube Pendant method, widly used in commercial and industrial lighting.
- Update 7 years warranty Meanwell driver.
- Equipped with Cree XP-L chips, 118lm/w efficiency.
Specification
Model |
EL-HB06-150W |
LED Brand |
CREE XT-E/XPL-L |
Driver Brand |
MEANWELL/Inventronics |
Power Comsuption |
150W |
Input Voltage |
90v-305v AC/12-24v DC |
Power Efficiency |
>90% |
Power Factor |
>0.95 |
Surge Production Class |
3KV/6KV/10KV |
Lamp Rated Luminous Efficiency |
110lm/w |
Lamp Rated Lumen output |
16500lm (Lumen tolerance +/- 5%) |
Color Rendering Index |
>70 |
Color Temperature |
2700-7000K |
Working Environment |
Between -40℃~50℃,10%~90%RH |
Total Harmonic Distortion |
<15% |
Life span |
70000hours |
Wind Index |
Force 12 |
Body and Shell Materials |
Aluminum Alloy |
IP Rating |
IP65 |
Certification |
UL,TUV,GS,SAA,CB,CE&ROHS |
Optional Function |
0-10V DC or PWM Signal or Resistance Dimming Timer/ Photocell Contral
|
Warranty |
5 years |
Name |
80w-250w 110lm/w Mean well/ Inventronics driver 5 years warranty led high bay lighting |
Packing Details |
|
Fixture Dimension |
538X538X240mm |
Fixture Weight |
12.9KG |
Packing Dimension |
590X590X210mm |
Packing Weight |
14.1KG |
Product Details
1. 2 strandard versions to replace MH 250W and 400W highbays.
2. 3 ways of mounting options for any industrial and warehousing applications.
3. 5 types of beam angle options to meet anyprecises lighting requirements.
4. Reliable light output throughout lifetime.
5. Saves up to 60% energy compred to HD lighting system.
6. Attractive return on investment with superior performance.
7. Heavy and light industry with a a ceiling height of more than 8m.
8. Infrared sensor & dimmer option; Microwave sensor & dimmer option; photocell option.
More models of Everlite EL-HB06 series High bay Light are avaliable: 80-200w
Feature
- Die-casting aluminum body with anti-corrosion treatment.
- Highly polished alumin um reflector.
- IP65 rated for external use.
- High efficient and power factor led power supply
- Long life span over 70000 hours
- Obstain a 50%0-70% energy saving compared with Halogen lamps
Solar power street lighting system
The system is maily composed by five parts: LED street lights, solar panels, solar controller, strong battery and lamp-pole.
Intelligent Control System
The street light control system adopts PLC technology, through intelligent communication protocol, such as power line carrier and Zigbee to control every lamp, it can be widely used on street lighting system, control on-off, dimming control for specific lamp, check each lamp’s voltage, current, alarm for wire anomaly and failure, collect data and feedback system running status.
Concentrator
It communicates with each lamp through communication protocol to issue command and collect feedback data. Through Internet, WIFI to accept order from control center and feedback the nodes data.
Programmable time control dimmable LED driver
EVERLITELED street lights can be installed with dimmable driver that varies voltage from 0 to 10V DC and can also support intelligent communication protocol. Features including programmable dimming control, factory setting and accurate calibration etc.
eg: 150w LED steet light to replace the 400w HPS Lamp, ennergy-saving rate 68.75%, by dimming function, it is saving another 32%.
Light control LED street light
Through street lamp light controller, detecting the environment illuminance<10flux, after 30 seconds, it automatically turn on, detecting the environment illuminance>30lux, after 30 seconds, it automatically turn off.
Reference Table
We recommend the following configuration, according to the lamp power, temperature, sunshine radiation, continuously rainy days an every night working hours.
Solar System Installation
1. Reply your inquiry within 24 working hours.
2. Make customized products according to your requirement.
3. Finished goods in time and delivery as soon as possible all around the world.
4. Offer suitable prices based on customers required.
5. Honest and good after sales services.
6. Most professional solutions ever.
7. Non-stop updating products.
Production Process
Application
Company Overview
- Everlite LED Lighting Co., Limited, a professional manufacturer of outdoor LED street lighting, floodlighting and high bay lamps, located in Ningbo. It is consist of a completed lighting design teams, tooling and mold development shops, aluminum die-casting parts manufacturing facilities, paint finishing assembly lines, and lighting assembly lines.
- We are always keeping pace with the new development of led lighting industrial, which enable us to launch at least 3 new products per month. With the support of lighting designing engineers and lighting software , our service is far beyond than selling led lights, we help customers designing products, making tooling and testing products, planning and designing lighting projects,etc.
- Everlite are now selling its LED street lights, floodlighting and housing mainly to North and South America, Southeast Asia, Europe, Russia, China Mainland.
- Contact Us now to experience our good products and service.
Q: Are you manufacturer or trading company.
A: We are mainly manufacturer and also we can do trading, located in Ninghai,Ningbo,Zhejiang.
Q: Main products produced?
A: Outdoor lighting: led street light, flood light, high bay light, wall lamp, garden light.
Q: Required mainly certificates?
A: TUV, GS, SAA, UL, CB, CE, RHOS.
Q: Your main export market?
A: European, Mid-East, South-East Asia, Latin America, Africa, Australia.
Q: How many years warranty provide?
A: Standard version 5 years warranty for driver and chips, 10 years warranty for lights head.
Update Meanwell driver for 7 years warranty. Also 2-3 years warranty available.
Q: The advantages between you and others.
A: We have the most talent engineers and we are always honest to our clients, best quality conrol, best service and non-stop innovation.
