High quality and low price EM579 electric diesel fuel injection pump test machine from haishu 150, is designed mainly for fuel injection pump manufactories, scientific research institutions or repairing work to test, adjusting or repairing fuel injection pumps. It is the second-generation product after several major improvements of the first generation to meet the THAILAND customers’ needs.
This injection pump adopted the advanced frequency conversion technology to change the speed of the main motor; The customer can change the speed in a wide range ,can preset the required speed and measure the pressure oil supply value , the vacuum value and the pressure value of pump body and the oil return to tank at will.
This test bench has the latest new structure, proper location, beautiful outlook, and the installation. And operation become more conveniently.
The advantages of small speed fluctuation, little power loss, and the long service life attribute part for the direct power output of the motor. The fuel can be cooled down by the air cooler, so the fuel temperature can be controled low than you require(can be presetting on CONTROLER).
High quality and low price EM579 test fuel pump diesel is high quality hi-stable character, hi-reliability, ultra-low-nise, perfect auto-protecting function and so on, It is advanced products.
Main properties and functions:
- 1. Rotation direction: Positive & Negative;
- 2. Output shaft speed range:0~4000rpm;
Output shaft speed and Stroke times setting and meter show
- 3. Test oil injection of each cylinder at any speed;
- 4. Checking injection time of each cylinder at static.
- 5. Test of sealing oil pump.
- 6. Checking of transfer pump.
8. Mechanical speed governors testing.
9.Test electromagnetic valve of distributor pump.DC 12V and DC 24V.
10.Distributor pump reflux delivery measuring.
11.Test pneumatic speed governors.
12.Test vacuum capacity of speed governor.
13.Check manifold pressure compensators (LDA)
14.Measuring internal pressure of distributor pump.
15.Diesel fuel temperature meter digital showing.
EM-579 test machine MAIN TECHNICAL PARAMETERS
test bench brand |
EMC579-55/75 |
EMC579-110/150 |
|
Output shaft Speed range (rpm) |
0~4000 |
0~4000 |
Direction of rotation |
Forward, reverse |
Forward, reverse |
|
Number of testable Cylinders |
12 |
12 |
|
Output power of Drive shaft (KW)
|
5.5/7.5 (7.5/10hp) |
11/15 (15/20hp) |
|
Height from the axis of output shaft to the surface of worktable (mm) |
125 |
125 |
|
Flow rate of the fuel System in liter/min |
≥6 |
≥8 |
|
Measuring internal pressure of distributor pump (MPa) |
≥1. 6 |
≥1. 6 |
Feed pressure ofTurbine oil (MPa) |
Low pressure≤0.4 high pressure≤4 |
Low pressure≤0.4 high pressure≤4 |
|
Flow rate of the Reflux delivery (liter/hour) |
0~10 |
0~10 |
Fuel stroke-counting range |
0~9999 |
0~9999 |
|
Control temperature range of fuel (°C) |
40±2 |
40±2 |
|
Gas positive Pressure (MPa) |
≥0.16 |
≥0.16 |
|
Gas negative Pressure (MPa) |
-0.1~0 (-760mmHg~0) |
-0.1~0 (-760mmHg~0) |
|
Overall of the test bench: (L×W×H) (mm) |
1850×1000×1750 |
1850×1000×1750 |
Weight (Kg) |
850/900 |
1000/1100 |
