water filling line
Feature:
1. The machine is mainly used in the beverage filling operations. It is suitable for non-carbonated drink filling machine.
2. Water bottling machine, it is a fully automatic and multi-functions combined machine, which integrates bottle rinser, filler and screw capper in one unit.
3. The machine can also be used in hot filling if it is installed with temperature controlling device. The handle of the machine can be freely and conveniently turned to adjust the machine to fill various types of bottles.
4. The filling operation is faster and more stable because the micro pressure filling operation of the new type is adopted.
5. The advanced OMRON programmed controller (PLC) is adopted to control the machine to run automatically while a transducer is used in the bottle -entering chains to adjust speeds and coordinated with the transducer of the main machine to make the operations of moving bottle forward steadily and reliably.
6. It is convenient to operate with higher automation because every part of the machine is inspected to run with photo electricity. On the bases, the filling parts of the machine can be changed into filling methods of lower vacuum. The filling category of lower vacuum (Z type machine) is applicable in glass bottles, filling alcohol, soy and such like materials. The aluminum theft proof cap and plastic cap can be adopted.
7. We have embraced only those technologies that are the most practical and the most cost effective to own and operate.
8. We only offer those technologies which provide the best versatility, flexibility and reliability for the cost.
9. The filling machines we offer are listed below some information that will help you understand how to select the type and capacity filler you need for your operations.
Main Technical Data:
Model: |
CGF16/12/6 |
CGF18/18/6 |
CGF24/24/8 |
CGF32/32/12 |
CGF40/40/12 |
CGF48/48/12 |
Production Capacity:500ml(B/h) |
4000 |
6000 |
10000 |
14000 |
17000 |
20000 |
Suitable Bottle Standard:(mm) |
150-300 |
150-340 |
150-340 |
150-340 |
150-340 |
150-340 |
Suitable Cap Standard:(mm) |
φ50-φ110 |
|||||
Filling Pressure:(mpa) |
0.2-0.3 |
|||||
Installed Power |
3.13 |
3.84 |
3.84 |
5.6 |
6.3 |
7.3 |
Filling Temperature: |
Room Temperature |
Room Temperature |
Room Temperature |
Room Temperature |
Room Temperature |
Room Temperature |
Overall Size:L×W×H(mm) |
2400×1670 |
2470×1970 |
2865×2170 |
3700×2570 |
3800×2950 |
4500×3400 |
Total Weight:(kg) |
2500 |
3000 |
4000 |
5000 |
6000 |
7000 |
