Machines to Make Plastic Bottles
Introduction
It is suitable for producing PET plastic containers and bottles in all shapes. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle and hot fill bottle etc.
Machines to Make Plastic Bottles
Features
The Semi-automatic Plastic Bottle Making Line is suitable for producing PET plastic containers and bottles from 50-2000ml. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle etc. 1. Adopting double crank to adjust mould ,heavy locking mould, stable and fast ,Adopt infrared oven to heat the perform ,the perform rotated and heated equally. 2. The air system has been divided into two parts: pneumatic action part and bottle blow part to meet the different requirements for the action and blow .It can provide sufficient and steady high pressure for blowing large irregular shaped bottles. 3. The line is also equipped with muffler and oiling system to lubricate the mechanical part of the machine. 4. The line can be operated in the step-by-step mode and the semi-auto mode. 5. The line is small with low investment, easy and safe to operate .
Machines to Make Plastic Bottles
Technical Parameters
Name | Item | Unit | Details |
Semi-automatic PET Bottle Production / Making / Producing Line | Dimension | mm | 1600*600*1610mm |
Weight | kg | 500 | |
Bottle volume (max) | ml | 2000 | |
Bottle volume (min) | ml | 50 | |
Bottle Neck Diameter (max) | mm | 40 | |
Bottle Neck Diameter (min) | mm | 18 | |
Body Diameter (max) | mm | 125 | |
Body Height( max) | mm | 420 | |
Number of Cavities | mold | 2 | |
Production output | pcs/h | 1200-1600BPH | |
Clamping force | T | 5.7(56KN) | |
Mold thickness | mm | 200(max) | |
Mold width | mm | 360x390 | |
Space between Tie-bars | mm | 120-220 | |
Diameter of Tie-bars | mm | 63 | |
Scope of Tie-bars | mm | 405 | |
Mold stroke | mm | 160 | |
Stretching stroke (max) | mm | 420 | |
Working pressure | Mpa | 0.8-1.0Mpa | |
Blowing pressure | Mpa | 2.0-3.0Mpa | |
Voltage/Power | V/KW | 220V/1KW | |
Weight | Kg | 500 | |
Pre-heater
| Dimension | mm | 1870*630*1450mm |
Weight | kg | 260 | |
Voltage/Power | V/KW | 380V/14KW |
Machines to Make Plastic Bottles
