Product Details
Condition: | New | Application: | Beverage | Packaging Type: | Bottles, Other, Bottles, PET Bottles |
Packaging Material: | Plastic, Wood | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | AS PER CLIENT'S FACTORY | Power: | 3KW | Place of Origin: | Jiangsu, China |
Brand Name: | Chunyuan machine | Model Number: | DCGF | Dimension(L*W*H): | 3200*1600*2100MM |
Weight: | 3000KGS | Certification: | CE AND ISO | After-sales Service Provided: | Overseas service center available |
Product Description
Model Constant Pressure Filling Machine
Soft / carbonated drink bottle filling machine , it can fill gas water ,carbonated beverage soda water in filling line
Carbonated Beverage Filling machine
1.Capacity:5000-6000bph.
2.Filling Volume(L):250ml-1500ml
3.Suitable bottles :PET &glass Bottle.
ISO&CE certificate
Soft drink washer filler capper three in one
Model: | DCGF18-18-6 | DCGF24-24-8 | DCGF32-32-12 | DCGF40-40-12 | ||
capacity :500ml | 5000 | 8000 | 12000 | 18000 | ||
bottle shape: | roud or square | |||||
PET bottle: (mm) | (Bottle Diameter):φ50-.φ110mm (Height):150-340mm | |||||
cap: | PE srew cap | |||||
filling precision: | ≤±5mm | |||||
filling pressure:(Mpa) | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | ||
rinsing pressure:(Mpa) | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | ||
filling volume :(L) | 3.5 | 4 | 6 | 8 | ||
overall size:(mm) | 2450*1800 *2350 | 2780*2200 *2350 | 3600*2650 *2350 | 3800*2950 *2400 | ||
weight: (kg) | 3500 | 4500 | 5500 | 6500 |
