pressure filling machine
DXGF series constant pressure washing, filling and capping 3in1 unit
The series equipment is used in producing all kinds of carbonated drink packed with PET bottles. Washing, filling and sealing devices equipped on the same machine. The design of the machine is scientific and reasonable. The appearance is beautiful and the function is complete. Its operation and maintenance is convenient. Its automation is high. The advanced technology from Italy and Germany are employed. The speed of filling is fast and the liquid amount is controlled accurately. The filling can be stopped automatically when there is no bottle or bottles are damaged. The advanced auto-washing technology is used in system. Pneumatic valve and damped gears are used for bottle conveying, the noise is low and the whole machine runs smoothly. The magnetic torque is used for screw capping. The power of screw capping can be adjusted without steps. The power of screw capping can also be fixed, and the caps will not be damaged, the capping is shortage of caps in the caps storage tank, an alarm signal will be generated and the caps will be fed automatically. The whole machine is controlled by PLC with touch-screen as the interface between human and machine. The amount of the drinks in the drink tank can be controlled automatically. The filling and capping will be stopped automatically when there is no bottle. When are cramped wrongly or when caps are not available, the machine can be stopped automatically.
Model |
DXGF18-18-6 |
DXGF24-24-8 |
DXGF32-32-10 |
DXGF40-40-10 |
DXGF50-50-12 |
Capacity(500ml)(b/h) |
6000 |
8000 |
12000 |
15000 |
18000 |
Total power(kw) |
5.18 |
6.58 |
8.18 |
9.2 |
10.1 |
Bottle shape: |
roud or square |
||||
PET bottle: (mm) |
(Bottle Diameter):φ50-.φ110mm (Height):150-340mm |
||||
Bap |
PE srew cap |
||||
Filling precision: |
≤±5mm |
||||
Filling pressure:(Mpa) |
0.15-0.35 |
||||
Rinsing pressure:(Mpa) |
0.2-0.25 |
||||
Filling volume :(L) |
3.5 |
4 |
6 |
8 |
10 |
Overall size:(mm) |
2450×1800×2350 |
2780×2200×2350 |
3600×2650×2350 |
3800×2950×2400 |
3800×2950×2400 |
Weight: (kg) |
3500 |
4500 |
5500 |
||
