Help CenterReverse Osmosis Water System
Related Products
Specifications
reverse osmosis water systemWater Recovery Rate 50-75%
Continuous operating
RO membrane:DOW
reverse osmosis water system
UF, the abbreviation of ultra filtration, is a process of separating suspended macromolecules from wastewater by using membrane and pressure differential. The membrane used in the process is a selectively permeable membrane which resists survival of macromolecules above a certain size when passing through,and it’s in this manner, it becomes an expert in retaining macromolecules, colloids, microorganisms and pyrogens.
What is RO (reverse osmosis)
Reverse osmosis is the process of forcing a solvent from a region of high solute concentration through a semipermeable membrane to a region of low solute concentration in the result of applying an external pressure to reverse the natural flow of pure solvent.
Reverse osmosis is in the final category of membrane filtration, 0.1nm , to remove pollutants and microorganisms.
Ro is a common method of desalination,groundwater purification, drinking water purification, removing minerals from boiler water.
This system feature simple user-friendly controls,sturdy construction, easy access for maintenance and installation.
Advantages:
l 97% Desalination Rate
l 50%-75% Recovery Rate
l Low operation cost
l Reliable and stable
l Reach relevant standard of state or enterprise
l Simple system integration with high efficiency and low noise
l Flexible system configurations to meet a wide range of needs
l Engineered to last with all stainless steel components,
Brief flow chart:
raw water pump- sand filter-activated carbon filter-micro filter-ultrafiltration device- ozone mixing tank -1st pure water filling line-high pressure pump-reverse osmosis device-ozone mixing tank-2nd pure water filling line
We can design any project of the water treatment to meet the demands of our clients, considering both the quality of the raw water and the desired standard of the treated water.
The system is made of SS304 and SS316; in order to save place at site, ultrafiltration part is combined with reverse osmosis part by a same rack, please see the picture below
