Help CenterAgriculture Irrigation Pipe 10 Inch Pvc Lay Flat Hose
Related Products
-
Agriculture Pump Irrigation 1-12'' Inch Colored Pvc PipeUS$ 0.6 - 15MOQ: 500 Meters -
Agricultural Hose Water Delivery PipeUS$ 3.2 - 12MOQ: 500 Meters
-
Agriculture Pump Industry Lay Flat Pvc Pipe 300mmUS$ 0.6 - 15MOQ: 500 Meters
-
ISO Standard 1-12'' Inch High Pressure Water Hose Layflat Hose PipeUS$ 0.6 - 15MOQ: 500 Meters
-
ISO Standard Lay Flat 8 Inch Flexible PipeUS$ 0.6 - 15MOQ: 500 Meters
This hose is designed as a standard duty hose for water discharge in Agricultural Irrigation, industrial and construction applications,and is economical and rolls up flat for easy and storage, resists kinking and twisting.
Tube: PVC compound
Cover:PVC compound
Reinforcement: High strength polyester yarn jacket
Temperature: -20 to +80 degree
Low and Medium Pressure PVC Lay Flat Hose | |||||
Inch |
Diameter (mm) |
Thickness (mm) |
W.P. (Bar) |
B.P. (Bar) |
Length (m/roll) |
1 |
25.4 |
1.4-2.2 |
2-10 |
6-30 |
200m max
|
1 1/2 |
38.1 |
1.4-2.2 |
2-10 |
6-30 |
|
2 |
50.8 |
1.4-2.4 |
2-10 |
6-30 |
|
2 1/2 |
63.5 |
1.5-2.4 |
2-10 |
6-30 |
|
3 |
76.2 |
1.5-2.5 |
2-10 |
6-30 |
|
4 |
102 |
1.5-2.6 |
2-10 |
6-30 |
|
5 |
127 |
1.5-2.6 |
2-10 |
6-30 |
|
6 |
152 |
1.6-2.8 |
2-10 |
6-30 |
|
8 |
203 |
1.8-3.0 |
2-10 |
6-30 |
|
10 inch |
254 |
2.0-3.2 |
2-10 |
6-30 |
|
12 |
304 |
2.4-3.4 |
2-10 |
6-30 |
|
2. PVC/NBR layflat flexible irrigation hose
Construction:
The hose is made from extruded thermoplastic polyester based 70% PVC with 30% NBR. The reinforcement is made from circular woven filament polyester yarn.
The "extrusion through-the-weave" production method gives a very strong bonding
between cover and lining as well as firmly encapsulating the woven polyester.
Feature:
UV resistance, lighter and less bulky than most rubber discharge hose.
Resist abrasion and weathering, Resit kinking and stretching while in service.
More economic solutions replace NBR layflat hose and TPU layflat hose in some cases.
Application:
Suitable for use and recommended for industrial and agriculture applications in: Dewatering and operations, Frac water transfer, Distribution of slurry and manure as fertilizer. Fuel, oil and chemical transfer.
High Pressure PVC with NBR Lay Flat Hose | |||||
Inch |
I.D. (mm) |
Thickness (mm) |
W.P. (Bar) |
B.P. (Bar) |
Length (m/roll) |
1 |
25.4 |
2.2-2.8 |
10-25 |
30-75 |
200m max |
2 |
38.1 |
2.2-3.0 |
10-25 |
30-75 |
|
2 1/2 |
50.8 |
2.2-3.5 |
10-25 |
30-75 |
|
3 |
63.5 |
2.2-3.5 |
10-25 |
30-75 |
|
4 |
76.2 |
2.2-4.0 |
10-25 |
30-75 |
|
5 |
102 |
2.2-4.0 |
10-25 |
30-75 |
|
6 |
127 |
2.2-4.0 |
10-15 |
30-45 |
|
8 |
152 |
2.2-4.0 |
10-15 |
30-45 |
|
10 inch |
203 |
3.0-4.0 |
10 |
30 |
|
12 |
254 |
3.0-4.0 |
10 |
30 |
|
1. Hose Specification
We can produce lay flat hose acording to your request on Inner Diameter, working pressure and length per roll.Before send you right quotation, pls kindly confirm with me.
2. About sample before order
We can supply 20-50cm free sample for your test or little longer, you just need to pay express freight or we can do freight collect.
3. MOQ
Usually MOQ is 1000m
4. Contact Information
Skype:qiaofangwin8
Whatsapp:008615762983159
Email: fang (@)
QQ:2285548034
facebook: PVC layflat hose
