Specifications
1. DXGF series constant pressurecarbonated beverage washing, filling, sealing machine
2.Product caacity:3000~18000b/h
3. ISO
Product Description
The series equipment is used in production of PET bottle-packing carbonated beverage such as Coca-Cola, containing gas mineral water, sprite, containing gas juice etc. The machine combines washing/filling/capping with complete automation, and the filling process adopted the micro-pressure technology, which makes filling process faster and more stable. The capacity can be from 3000 to 12000B/H.
Characteristic:
1. It can carry out bottle washing filling and capping in one machine.
2. The whole machine designing is reasonable. The appearance is beautiful and the maintenance is convenient.
3. It adopts bottleneck blocking type conveying-bottle structure to make changing bottle model more convenient, faster and easier.
4. The main machine adopts advanced PLC control technology. The key electric elements are adopting international famous products.
Technical Specifications
Model | DXGF14-12-5 | DXGF18-18-6 | DXGF24-24-8 | DXGF32-32-10 | DXGF40-40-12 |
Washing Heads | 14 | 18 | 24 | 32 | 40 |
Filling Heads | 12 | 18 | 24 | 32 | 40 |
Caping Heads | 5 | 6 | 8 | 10 | 12 |
Capacity(b/h) | 3000 | 4000 | 6000 | 8000 | 12000 |
Filling Precision | ≤+5mm | ≤+5mm | ≤+5mm | ≤+5mm | ≤+5mm |
Power(Kw) | 2.2 | 3.75 | 4.8 | 5.5 | 6.3 |
Wight Kg | 2500 | 3500 | 4800 | 5600 | 6500 |
Size(mm) | 2250x1700x2300 | 2400x1960x2300 | 3010x2180x2400 | 4000x2250x2500 | 4200x3000x3150 |
More photos:
