US$ 10,000 - 15,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage
Packaging Type:
Bottles, Cartons
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Beverage
Packaging Type Bottles, Cartons
Packaging Material Plastic, Wood
Automatic Grade Automatic
Driven Type Electric
Voltage AS PER CLIENT'S FACTORY
Power 2KW
Place of Origin Jiangsu, China
Brand Name Chunyuan
Model Number XGF
Dimension(L*W*H) 2200*1600*2100MM
Weight 2000KGS
Certification CE AND ISO
After-sales Service Provided Engineers available to service machinery overseas

 water packing machine

The equipment is used in production line of non-carbonated drink, like PET bottle minerial water and pure water.

Washing, filling, capping are integrated in one machine. The whole machine has scientific and reasonable design, beautiful appearance, it is easy operation and maintenance.

it adopted gravity filling mathed.filling speed is fast, and it filling accurately avoiding leackage. Spring cramps are used in the bottle washing process. The empty can be turned over 180 degree along the conveying rail. Two times of internal and external washing. the efficiency washing is good. The magnetic torque is used for screw capping. The power of screw capping can be adjusted.

The power of the screw capping also can be fixed, and the caps will not be damaged, its capping is reliable. The whole machine is controlled by PLC with touch-screen as the human-machine interface.

The level of the drinks in the tank can be controlled automatically. The filling and capping will be stopped when there is no bottle. When bottles are cramped wrongly or when caps are not available, the machine can be stopped automatically.  The production capacity can be adjusted conveniently.

Model

XGF12-12-6

XGF18-18-6

XGF24-24-8

XGF32-32-8

XGD40-40-10

XGF50-50-12

Bottle Shape

roud or square

PET Bottle(mm)

(Bottle Diameter):φ50-.φ110mm   (Height):150-340mm

Cap:

PE srew cap

Filling Precision:

≤±5mm

Filling Pressure:(Mpa)

0.15-0.35

Rinsing Pressure:(Mpa)

0.2-0.25

Capacity(500ml)

4000b/h

6000b/h

10000b/h

14000b/h

18000b/h

24000b/h

Total power(kw)

3.58

4.68

6.58

9.68

9.68

10.8
