Professional Broadband day feeder series surge protector
Description
LRF1 is a coaxial lightning current and surge protector, fixed installation. Can meet the highest requirements of switches and other RF communication equipment.
Parameter
Product number |
LRF1-NJK |
Protection level Up |
≤600V |
Nominal discharge current(8/0.02mS) In |
10KA |
Maximum discharge current(8/0.02m S) Imax |
20KA |
Maximum frequency of use |
0-3GHz |
insertion loss |
0.1db |
LRF1-NJK | |
In Bobbi |
≤1.2 |
characteristic impedance |
50 Ω |
Connection and installation | |
Recommended connection type |
50 Ω |
Install method |
perforation Fixed installation |
Installed environment |
No significant vibration and shock |
protection class |
IP20 |
Elevation |
≤4000m |
Relative humidity |
30%~90% |
| Protection mode | |
| Interface mode | BNC/TNC/N/SMA/L29/customize |
| Protection mode | Inner conductor-Outer conductor |
Please kindly contact us for more details!
